8
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-1. UPPER CASE
(BVTT 3 × 6)
5 Upper case
3 Four screws
(BVTP3 × 8
)
1 Three screws
(CASE3 TP2)
4Three screws
2 Three screws
(CASE3 TP2)
(Remove in the direction of the arrows)
3-2. FRONT PANEL SECTION
(BVTP3 × 8)
Connector
(CN802)
Two lugs
Claw
4 Two connectors
(CN452, 702)
Wire (flat type)
(15 core) (CN303)
Wire (flat type)
(17 core) (CN304)
Wire (flat type)
(13 core) (CN431)
7 Two screws
(BVTP3 × 8)
Lug
Front panel section
(Be careful in has claws)
1
2
3
0
9
8
Screw (BVTP3 × 8)
5
6
Screw
(BVTP3 × 8)
Four screws
