— 8 —
3-4.
CD SW BO
ARD AND PANEL BO
ARD
3-3.
TC MECHANISM DECK
1
Push the EJECT button.
3
Six screws
(BVTP2.6x8)
2
T
wo cassette lid
4
TC Mechanism deck
1
Knob (V
OL)
2
Nut
3
Six screws
(BVTP2.6x8)
4
Four scre
ws
(BVTP2.6x8)
5
Five scre
ws
(BVTP2.6x8)
6
T
wo scre
ws
(BVTP2.6x8)
7
HP board
8
cla
w
9
CD SW board
0
T
wo claws
!¡
T
wo cla
ws
!™
Claw
!£
P
anel board
7
9
