Sony HVO-550MD Service Manual

Section 5
Service Menu
5-1. Operational Procedures
ENTER
MENU
REC
PLAY STOP CUSTOM
PAUSE EJECT
BACK
USB1 SERVER HDD DVD
123
No. Name Function
1 [MENU] key Displays the menu.
2 [↑]/[↓]/[←]/[→] key Shifts the cursor
3 [ENTER] key Determine the selection, or execute the operation.
HVO-500MD/HVO-550MD
5-1

Sony HVO-550MD Specifications

General

Display	LCD
Product color	White
USB connectivity	Yes
Playback resolutions supported	1280 x 720
BNC input ports	1
USB 2.0 ports quantity	4
HDD capacity	500 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Optical drive type	DVD-R

Weight and Dimensions

Weight	3200 g
Dimensions (WxDxH)	212 x 290 x 10.5 mm
