Sony HVO-550MD - Page 60

8. Remove the two gaskets and the spacer from the DVD drive.
DVD drive
Spacer
Gaskets
Reuse wire press clamp
SATA cable
Clamp
Harness
B2 x 3
(Tightening torque: 0.15
± 0.015 N•m)
B2 x 3
(Tightening torque: 0.15
± 0.015 N•m)
9. Install the removed parts by reversing the steps of removal.
Tip
After replacing the DVD drive, the unit is automatically rebooted by turning power on.
HVO-500MD/HVO-550MD
6-8
