21
Multi Function Dial Command
This command controls the GUI cursor operation.
CCW/CW move the GUI cursor, and Press/
R
elease commands apply the setting at the
cursor position.
Note that if a Press/Release pair is received on
the
shooting screen of the unit, direct menu
operation starts. It is not represent a long-press
operation.
Also, you cannot select a face/eye detection
f
rame or move the focus area using these
commands.
Direct Menu Command
This command moves the cursor to a specified
setup item in the direct menu of this unit. It can
also be used to exit the direct menu.
The movement destination depends on the
inte
rval between receiving Press/Release
commands.
VISCA Command Setting
Values
Value is a hexadecimal value.
ND filter
Pan/tilt position
Parameter
name
Interval < 1 sec Interval ≥ 1 sec
ND Filter
(Variable)
ND filter value Auto/Manual/
Cl
ear switching
ND Filter
(Preset)
(Disabled) Clear/Preset1/
Pr
eset2/Preset3
switching
Iris Iris value Auto/Manual
sw
itching
ISO/Gain ISO value/Gain
va
lue
Auto/Manual
switching
Shutter
(Speed)
Shutter value Auto/Off/Speed/
EC
S switching
Shutter
(Angle)
Shutter value Auto/Angle/ECS
sw
itching
AE Mode/Level Exposure
co
mpensation
value
Backlight/
Standard/Spotlight
switching
Value ND Filter
00 1/4
01 1/5
02 1/6
03 1/7
04 1/8
05 1/10
06 1/11
07 1/13
08 1/16
09 1/19
0A 1/23
0B 1/27
0C 1/32
0D 1/38
0E 1/45
0F 1/54
10 1/64
11 1/76
12 1/91
13 1/108
14 1/128
Value Position
Pan 09ca7 170°
00000 0°
f6359 –170°
Tilt
(when Ceiling setting
of c
amera is Off)
0b3b0 +195°
00000 0°
fe45b –30°
Tilt
(when Ceiling setting
of c
amera is On)
00dd2 +15°
00000 0°
f3e7d –210°
