Sony ILME-FR7 - VISCA Camera IP Setup Configuration; VISCA IP Setup Inquiry Process; VISCA IP Setup Network Settings

23
Camera IP Setup
Command
The following command is provided for setting
the IP address and camera name of a camera.
To set the network settings of a camera, use the
f
ollowing sequence.
Connect the computer used for configuring to
the
same network segment as the cameras.
1 Inquiry
The controller sends inquiry packets to UDP
b
roadcast address (255.255.255.255) on the
specified port number (52380). The camera
responds using inquiry response packets.
2 Network settings
The controller sends network setting packets
t
o UDP broadcast address (255.255.255.255)
on the specified port number (52380). The
camera refers to the MAC address units in
the packets and if the packets are a request
to itself, the camera returns an
acknowledgment (ACK) in the network
settings response.
If the camera configuration is unsuccessful,
i
t returns NACK in the network settings
response.
*1: ASCII code.
*2: ASCII code. For NACK, returns “NAK:**-**-**-**-**-**”.
*3: ASCII code. If necessary, a detailed message reply can occur
h
ere. May be omitted.
Notes
• Up to 8 characters comprising alphanumeric
characters or spaces can be used for the
camera name (NAME).
• When the WRITE data in the inquiry response is
se
t to off, you cannot change the camera IP
address and camera name in the network
settings.
• After power to the unit is first turned on, WRITE
is se
t to off automatically after 20 minutes, at
which point the network settings are no longer
accepted.
No. Name Description
1 Setting Protocol:
Inquiry
Controller inquires about the
n
etwork settings of the
camera.
2 Setting Protocol:
Inquiry response
Camera responds to the
i
nquiry from the controller.
3 Setting Protocol:
Network settings
Controller configures the
n
etwork settings of the
camera.
4 Setting Protocol:
Network settings
r
esponse
Camera responds to the
n
etwork settings from the
controller.
Command Data
Inquiry
UDP
Broadcast address
(255.255.255.255)
Specified port
num
ber (52380)
02
ENQ:network
*1
FF
03
Inquiry response
UDP
Broadcast address
(255.255.255.255)
Specified port
num
ber (52380)
02
MAC:**-**-**-**-**-**
*1
FF
MODEL:IPCARD
*1
FF
SOFTVERSION:**.**.**
*1
FF
IPADR:***.***.***.***
*1
FF
MASK:***.***.***.***
*1
FF
GATEWAY:***.***.***.***
*1
FF
NAME:xxxxxxxx
*1
FF
WRITE:on
*1
FF
03
Network settings
UDP
Broadcast address
(255.255.255.255)
Specified port
num
ber (52380)
02
MAC:**-**-**-**-**-**
*1
FF
IPADR:***.***.***.***
*1
FF
MASK:***.***.***.***
*1
FF
GATEWAY:***.***.***.***
*1
FF
NAME:xxxxxxxx
*1
FF
03
Network settings
r
esponse
UDP
Broadcast address
(255.255.255.255)
Specified port
num
ber (52380)
02
ACK:**-**-**-**-**-**
*2
“xxxx”
*3
FF
03
