Sony MEX-N5300BT User Manual

25GB
AUTOPAIR (auto pairing)
Starts BLUETOOTH pairing automatically
when iOS device version 5.0 or later is
connected via USB: [ON], [OFF].
BT SIGNL (BLUETOOTH signal) (page 10)
Activates/deactivates the BLUETOOTH
function.
BT INIT (BLUETOOTH initialize)
Initializes all the BLUETOOTH related
settings (pairing information, device
information, etc.): [YES], [NO].
When disposing the unit, initialize all the
settings.
(Available only while the source is off and
the clock is displayed.)
VOICE-OUT (voice output)
Selects the speakers for handsfree calling:
[VOICE FRONT] (front speakers), [VOICE
REAR] (rear speakers), [VOICE ALL] (all
speakers).
(Available only while the source is off and
the clock is displayed.)
“Sony | Music Center” Setup
(SONY APP)
Establish and terminate “Sony | Music
Center” function (connection).
Updating the Firmware
To update the firmware, visit the support site
on the back cover, then follow the online
instructions.
Note
During the update, do not remove the USB device.
Precautions
•Do not leave the front panel or audio
devices on the dashboard.
•When the unit is turned on, the power
antenna (aerial) extends automatically.
• Do not splash liquid onto the unit.
Moisture condensation
Do not splash liquid onto the discs. When
moisture condensation occur inside the unit,
remove the disc and wait for about an hour
for it to dry out; otherwise the unit will not
operate properly.
•Do not expose discs to direct sunlight or
heat sources such as hot air ducts, nor
leave it in a car parked in direct sunlight.
•Wipe the discs with a
cleaning cloth from the
center out. Do not use
solvents such as
benzine, thinner,
commercially available
cleaners.
•This unit is designed to
play discs that conform
to the Compact Disc (CD) standard.
DualDiscs and some of the music discs
encoded with copyright protection
technologies do not conform to the
Compact Disc (CD) standard, therefore,
these discs may not be playable by this
unit.
Additional Information
Notes on discs

Sony MEX-N5300BT Specifications

General

DIN size	1 DIN
Impedance	4 Ω
Output power	220 W
Product color	Black
Volume control	Rotary
Disc types supported	No
Audio output channels	4.0 channels
Equalizer bands quantity	10
Maximum power per channel	55 W
Smartphone remote support	Yes
Mobile operating systems supported	Android
Audio formats supported	AAC, FLAC, MP3, WMA
Display type	LCD
Illumination color	Multi
USB version	2.0
Bluetooth version	3.0+HS
USB port position	Front
Bluetooth profiles	A2DP, AVRCP, HFP, OPP, PBAP, SPP
Line outputs (RCA)	2
USB connector type	USB Type-A
USB ports quantity	1
Bluetooth functions	Audiostreaming, Handsfree calling
Supported radio bands	AM, FM
Preset stations quantity	30
Hands-free calling	Keep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e

Weight and Dimensions

Depth	176 mm
Width	178 mm
Height	50 mm
Weight	1200 g
