7-2. CHASSIS SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
@
51 X-3379-555-1 CHASSIS ASSY, SET
52 3-222-779-01 SPRING (OPEN), TENSION
* 53 A-3323-650-A MAIN BOARD, COMPLETE (R700:CND,AEP,UK,E,
AUS,EE,JE,FR,AR,HK,CH,TW,KR)
* 53 A-3323-652-A MAIN BOARD, COMPLETE (G750:AEP,UK,E,AUS,
CET,JE,FR,HK,KR)
* 53 A-3323-694-A MAIN BOARD, COMPLETE (R700:US)
* 53 A-3323-703-A MAIN BOARD, COMPLETE (G750:US)
54 3-222-780-01 SPRING, TORSION
55 4-218-233-09 SCREW (1.7), MI
56 3-335-797-01 SCREW (M1.4X2), TOOTHED LOCK
57 3-318-382-01 SCREW (1.7X3), TAPPING
58 3-222-837-01 SPRING, BATTERY COIL
59 3-222-838-01 ARM
60 X-3379-899-1 CASE ASSY, BATTERY
