Sony NEX-FS700 Service Manual

– 2 –
NEX-FS700/FS700K/FS700C/FS700CK/FS700E/FS700EK/FS700J/FS700JK/FS700R/FS700RH/FS700U/FS700UK
SPECIFICATIONS
System
Video signal
NTSC color, EIA standards
HDTV 1080/60i, 1080/60p, 720/60p
specification
PAL color, CCIR standards
HDTV 1080/50i, 1080/50p, 720/50p
specification
Video recording system
HD image quality: MPEG-4 AVC/
H.264 AVCHD format Ver. 2.0
compatible
SD image quality: MPEG-2 PS
Audio recording system
Linear PCM 2ch (48 kHz 16-bit)
Dolby Digital 2ch (48 kHz 16-bit)
Dolby Digital Stereo Creator employed
Still image recording system
DCF Ver. 2.0 Compatible
Exif Ver. 2.3 Compatible
MPF Baseline Compatible
Recording media (movies/still images)
“Memory Stick PRO Duo” media
Flash memory units
SD card (Class 4 or faster)
Image device
“Exmor” Super35 CMOS sensor
25.5 mm × 15.6 mm
Gross: Approx. 11 600 000 pixels
Effective (movie): Approx. 8 300 000
pixels (16:9)
Effective (photo): Approx. 8 400 000
pixels (16:9), Approx. 7 100 000 pixels
(3:2)
Recording pixels (photo):
Approx. 8 300 000 pixels (16:9),
Approx. 7 000 000 pixels (3:2)
Color temperature
[AUTO]
(one push) A/B
[INDOOR] (3 200K)
[OUTDOOR] (5 800K)
Minimum illumination
1.2 lx (lux)* with Shutter Speed 1/24,
auto gain control, auto iris (when
selecting [60i])
1.5 lx (lux)* with Shutter Speed 1/25,
auto gain control, auto iris (when
selecting [50i])
* Using the E 18-200mm F3.5-6.3 OSS lens
Input/output connectors
VIDEO OUT jack
Pin connector
1 Vp-p, 75 Ω (ohms) unbalanced, sync
negative
AUDIO OUT jacks
Pin connectors
-10 dBu (at load impedance 47 kΩ
(kilohms)), Output impedance with less
than 2.2 kΩ (kilohms)
(0 dBu = 0.775 Vrms)
COMPONENT OUT jack
Mini-D jack
Y: 1 Vp-p, 75 Ω (ohms)
P
B/PR, CB/CR: 0.7 Vp-p, 75 Ω (ohms)
REMOTE jack
Stereo mini-minijack (Ø 2.5 mm)
HDMI OUT jack
HDMI Connector (Type A)
SDI OUT jack
BNC
SMPTE259M/292M/424M/425M
compatible
USB jack
mini-AB
i (headphones) jack
Stereo minijack (Ø 3.5 mm)
INPUT1/INPUT2 jacks
XLR 3-pin × 2, female,
MIC: -48 dBu/3 kΩ (kilohms)
LINE: +4 dBu/10 kΩ (kilohms)
(0 dBu = 0.775 Vrms)
LCD screen
8.8 cm (3.5 type, aspect ratio 16:9)
Total dot number
921 600 (1 920 × 480)
General
Power requirements
DC 7.2 V (battery pack)
DC 7.6 V (AC Adaptor)
Average power consumption
During camera recording using the
microphone ECM-XM1, LCD with
normal brightness (using the E 18-200
mm F3.5-6.3 OSS lens*)
When selecting [60i]: 9.6 W
When selecting [50i]: 8.8 W
When Flash Memory Unit HXR-
FMU128 is used, the average power
consumption increases about 1.1 W.
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
Camcorder body only (including the
projecting parts):
145 mm × 178.5 mm × 253.5 mm
(5 3/4 in. × 7 1/8 in. × 10 in.) (w/h/d)
When recording (including the
projecting parts):
195.5 mm × 202.5 mm × 569.5 mm
(7 3/4 in. × 8 in. × 22 1/2 in.) (w/h/d)
(With the accessories (lens*, lens
hood*, large LCD viewfinder, large
eyecup, handle, microphone (ECM-
XM1), and grip (without the belt)
attached.))
Mass (approx.)
Camcorder body only:
1 680 g (3 lb 11 oz)
When recording:
3 060 g (6 lb 12 oz) (With the
accessories (battery pack (NP-F770),
lens*, lens hood*, large LCD
viewfinder, large eyecup, handle,
microphone (ECM-XM1), grip, and
flash memory unit cover) attached.)
* Supplied with NEX-FS700UK/FS700EK/
FS700K
AC Adaptor AC-PW10
Power requirements
AC 100 V - 240 V, 50 Hz/60 Hz
Power consumption
24 W
Output voltage
DC 7.6V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
127 mm × 35 mm × 63 mm
(5 in. × 1 7/16in. × 2 1/2in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
300 g (10 oz.) excluding the power cord
(mains lead)
* See the label on the AC Adaptor for other
specifications.
Charger AC-VL1
Power requirements
AC 100 V - 240 V, 50 Hz/60 Hz
Power consumption
22 W
Output voltage
DC 8.4 V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
136 mm × 51 mm × 90 mm
(5 3/8 in. × 2 1/8 in. × 3 5/8 in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
270 g (9.6 oz) excluding the power cord
(mains lead)
* See the label on the Charger for other
specifications.
Rechargeable battery pack NP-F770
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Maximum charge voltage
DC 8.4 V
Maximum charge current
3.0 A
Capacity
Typical: 31.7 Wh (4 400 mAh)
Minimum: 30.0 Wh (4 200 mAh)
Type
Li-ion
* Minimum focus is the shortest distance from the
image sensor to the subject.
Design and specifications are subject to change
without notice.
These specifications are extracted from the instruction manual of
NEX-FS700/FS700K/FS700E/FS700EK/FS700U/FS700UK.
SPECIFICATIONS
System
Video signal
NTSC color, EIA standards
HDTV 1080/60i, 1080/60p, 720/60p
specification
PAL color, CCIR standards
HDTV 1080/50i, 1080/50p, 720/50p
specification
Video recording system
HD image quality: MPEG-4 AVC/
H.264 AVCHD format Ver. 2.0
compatible
SD image quality: MPEG-2 PS
Audio recording system
Linear PCM 2ch (48 kHz 16-bit)
Dolby Digital 2ch (48 kHz 16-bit)
Dolby Digital Stereo Creator employed
Still image recording system
DCF Ver. 2.0 Compatible
Exif Ver. 2.3 Compatible
MPF Baseline Compatible
Recording media (movies/still images)
“Memory Stick PRO Duo” media
Flash memory units
SD card (Class 4 or faster)
Image device
“Exmor” Super35 CMOS sensor
25.5 mm × 15.6 mm
Gross: Approx. 11 600 000 pixels
Effective (movie): Approx. 8 300 000
pixels (16:9)
Effective (photo): Approx. 8 400 000
pixels (16:9), Approx. 7 100 000 pixels
(3:2)
Recording pixels (photo):
Approx. 8 300 000 pixels (16:9),
Approx. 7 000 000 pixels (3:2)
Color temperature
[AUTO]
(one push) A/B
[INDOOR] (3 200K)
[OUTDOOR] (5 800K)
Minimum illumination
1.2 lx (lux)* with Shutter Speed 1/24,
auto gain control, auto iris (when
selecting [60i])
1.5 lx (lux)* with Shutter Speed 1/25,
auto gain control, auto iris (when
selecting [50i])
* Using the E PZ 18-200mm F3.5-6.3 OSS lens
Input/output connectors
VIDEO OUT jack
Pin connector
1 Vp-p, 75 Ω (ohms) unbalanced, sync
negative
AUDIO OUT jacks
Pin connectors
-10 dBu (at load impedance 47 kΩ
(kilohms)), Output impedance with less
than 2.2 kΩ (kilohms)
(0 dBu = 0.775 Vrms)
COMPONENT OUT jack
Mini-D jack
Y: 1 Vp-p, 75 Ω (ohms)
P
B/PR, CB/CR: 0.7 Vp-p, 75 Ω (ohms)
REMOTE jack
Stereo mini-minijack (Ø 2.5 mm)
HDMI OUT jack
HDMI Connector (Type A)
SDI OUT jack
BNC
SMPTE259M/292M/424M/425M
compatible
USB jack
mini-AB
i (headphones) jack
Stereo minijack (Ø 3.5 mm)
INPUT1/INPUT2 jacks
XLR 3-pin × 2, female,
MIC: -48 dBu/3 kΩ (kilohms)
LINE: +4 dBu/10 kΩ (kilohms)
(0 dBu = 0.775 Vrms)
LCD screen
8.8 cm (3.5 type, aspect ratio 16:9)
Total dot number
921 600 (1 920 × 480)
General
Power requirements
DC 7.2 V (battery pack)
DC 7.6 V (AC Adaptor)
Average power consumption
During camera recording using the
microphone ECM-XM1, LCD with
normal brightness (using the E PZ 18-
200mm F3.5-6.3 OSS lens*)
When selecting [60i]: 9.9 W
When selecting [50i]: 9.0 W
When Flash Memory Unit HXR-
FMU128 is used, the average power
consumption increases about 1.1 W.
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
Camcorder body only (including the
projecting parts):
145 mm × 178.5 mm × 253.5 mm
(5 3/4 in. × 7 1/8 in. × 10 in.) (w/h/d)
When recording (including the
projecting parts):
195.5 mm × 202.5 mm × 569.5 mm
(7 3/4 in. × 8 in. × 22 1/2 in.) (w/h/d)
(With the accessories (lens*, lens
hood*, large LCD viewfinder, large
eyecup, handle, microphone (ECM-
XM1), and grip (without the belt)
attached.))
Mass (approx.)
Camcorder body only:
1 680 g (3 lb 11 oz)
When recording:
3 220 g (7 lb 1 oz) (With the
accessories (battery pack (NP-F770),
lens*, lens hood*, large LCD
viewfinder, large eyecup, handle,
microphone (ECM-XM1), grip, and
flash memory unit cover) attached.)
* Supplied with NEX-FS700RH
AC Adaptor AC-PW10
Power requirements
AC 100 V - 240 V, 50 Hz/60 Hz
Power consumption
24 W
Output voltage
DC 7.6V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
127 mm × 35 mm × 63 mm
(5 in. × 1 7/16in. × 2 1/2in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
300 g (10 oz.) excluding the power cord
(mains lead)
* See the label on the AC Adaptor for other
specifications.
Charger AC-VL1
Power requirements
AC 100 V - 240 V, 50 Hz/60 Hz
Power consumption
22 W
Output voltage
DC 8.4 V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
136 mm × 51 mm × 90 mm
(5 3/8 in. × 2 1/8 in. × 3 5/8 in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
270 g (9.6 oz) excluding the power cord
(mains lead)
* See the label on the Charger for other
specifications.
Rechargeable battery pack NP-F770
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Maximum charge voltage
DC 8.4 V
Maximum charge current
3.0 A
Capacity
Typical: 31.7 Wh (4 400 mAh)
Minimum: 30.0 Wh (4 200 mAh)
Type
Li-ion
Design and specifications are subject to change
without notice.
• Manufactured under license from Dolby
Laboratories.
These specifications are extracted from the instruction manual of
NEX-FS700R/FS700RH.
– ENGLISH –

Sony NEX-FS700 Specifications

General

HD type	-
Capture modes	FH, FXP, HQ, LP
Maximum frame rate	60 fps
Supported video modes	720p, 1080i, 1080p
Video formats supported	AVCHD, MPEG2, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	28 Mbit/s
Audio system	Dolby Digital 2.0
Built-in microphone	Yes
Audio formats supported	LPCM
Filter size	67 mm
Digital zoom	- x
Optical zoom	11.1 x
Image stabilizer	No
Focal length range	18 - 200 mm
Lens mount interface	Sony E
Maximum aperture number	6.3
Minimum aperture number	3.5
Focal length (35mm film equivalent)	27 - 300 mm
Sensor type	CMOS
Total megapixels	11.6 MP
Display diagonal	3.5 \
Display resolution	1920 x 480 pixels
Display resolution (numeric)	921600 pixels
Camcorder type	Handheld camcorder
Minimum illumination	1.2 lx
Camera shutter speed	1/60 - 1/2000 s
Battery life (max)	8.5 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Camcorder media type	Memory card
Compatible memory cards	MS PRO Duo Mark 2, MS Pro-HG, MS Pro-HG Duo HX, SD, SDHC, SDXC
Maximum memory card size	128 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
HDMI version	1.4
Composite video out	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black

Weight and Dimensions

Depth	101.5 mm
Width	126.5 mm
Weight	1470 g
