Sony PDW-F1600 User Manual

148
Maintenance Menu
Chapter 7 Menus
Maintenance Menu
Items in the maintenance menu
The following tables show the items in the maintenance
menu.
• Item names are the names which appear on the video
monitor of this unit and an external monitor to which the
output of the COMPOSITE OUTPUT 2 (SUPER)
connector, the SDSDI OUTPUT 2 (SUPER) connector,
or the HDSDI OUTPUT 2 (SUPER) connector is input.
An abbreviated name appears in the time data display
area when you press the NEXT button.
• The values in the Settings columns are the values which
appear in the time data display area. (The values may
appear in a different format on an external monitor. In
this case, the external monitor values are shown in
parentheses.) Underlined values are the factory defaults.
This manual does not explain the menu items in M0:
CHECK, M1: ADJUST, M2: SERVICE SUPPORT, and
M6: DRIVE. Refer to the Maintenance Manual for an
explanation of these items.
M3: OTHERS: Other setting items
Item Setting
M30: SOFTWARE VERSION Display of the software version of this unit
M31: SERIAL NUMBER Display of the serial number of this unit
M33: FILE I/F
CONFIG
PROAV DISPLAY Selects whether or not to display PROAV directory.
DISABLE
: Do not display PROAV directory.
ENABLE: Display PROAV directory.
PC REMOTE Disables or enables a FAM connection.
ENALBE
: Enable a FAM connection.
F-KEY SELECT: Enable or disable a FAM connection using the function menu.
M36: HOURS METER RESET Display and reset of the hours meter and the thread counter
M37: AUDIO
CONFIG
M370: HEAD ROOM Select the audio reference level (headroom).
–
20dB, –18dB, –16dB, –12dB, EBUL
Note
EBUL can be selected only when the system frequency is 50i/50P/25P.
M371: DATA LEN Select the audio channel configuration for IMX recording.
16bit
× 8ch: 16-bit, 8-channel configuration
24bit × 4ch: 24-bit, 4-channel configuration
M372: NON-AUDIO
INPUT
Select whether to handle digital audio signals as non-audio signals during
recording.
Audio (audio):
Handle as linear PCM audio signals.
data: Handle as non-audio signals.
Sub-Item
1 Tr1/Tr2
2 Tr3/Tr4
3 Tr5/Tr6
4 Tr7/Tr8
M373: INPUT LEVEL Set the upper limit for the signal level input to audio channels 1/3 or 2/4.
+4dB
, 0dB, –3dB, –6dB, EBUL
Note
EBUL can be selected only when the system frequency is 50i/50P/25P.
Sub-Item
1 CH1/CH3
2 CH2/CH4
M377: OUTPUT LEVEL Set the reference level for audio output signals.
+4dB
, 0dB, –3dB, –6dB, EBUL
Note
EBUL can be selected only when the system frequency is 50i/50P/25P.

Sony PDW-F1600 Specifications

General

Display	LCD
Internal	No
Product color	Black
USB connectivity	Yes
Video compression formats	MPEG, MPEG4
DC voltage	12 V
AC input voltage	100 - 240 V
Power consumption (typical)	80 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	25 - 90 %
BNC input ports	6
BNC output ports	9
USB 2.0 ports quantity	2
VGA (D-Sub) output ports	1
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Depth	396 mm
Width	210 mm
Height	132 mm
Weight	6500 g
