Sony PDW-F1600 User Manual

39
Connections and Settings
Chapter 3 Preparations
Editing Control Unit Settings
When connecting an editing control unit (BVE-700/700A/
2000) to use with this unit, set VTR constants as follows.
a) This is 15 when maintenance menu item M393: AUDIO DSP is set to
“AGC/limiter”.
.
a) When the PDBK-F1500 option is installed.
Using RM-280
The following figure shows a cut editing system
comprising a PDW-HD1500 as a player, a PDW-F1600
unit as a recorder, and an RM-280 as an editing controller.
System
frequency
VTR CONSTANT
1 2
3 4 5 6 7 8 9 10 11 12 13 14 15 16
59.94i/
59.94P/
29.97P
A0 97 00 96
07
a)
07
a)
03 80 0A 07 FE 00 80 5A FF 5A
50i/50P/25P A1 97 00 7D
07
a)
07
a)
03 80 0A 07 FE 00 80 4C FF 4B
23.98P A2 97 00 78
07
a)
07
a)
03 80 0A 07 FE 00 80 48 FF 48
F1600
System
frequency
VTR CONSTANT
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
59.94i/
59.94P/
29.97P
A0 96 00 96 15 15 03 80 0A 07 FE 00 80 5A FF 5A
50i/50P/25PA196007D151503800A07FE00804CFF4B
23.98P
a)
A2 96 00 78 15 15 03 80 0A 07 FE 00 80 48 FF 48
HD1500

Sony PDW-F1600 Specifications

General

Display	LCD
Internal	No
Product color	Black
USB connectivity	Yes
Video compression formats	MPEG, MPEG4
DC voltage	12 V
AC input voltage	100 - 240 V
Power consumption (typical)	80 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	25 - 90 %
BNC input ports	6
BNC output ports	9
USB 2.0 ports quantity	2
VGA (D-Sub) output ports	1
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Depth	396 mm
Width	210 mm
Height	132 mm
Weight	6500 g
