Sony SA-W2500 Service Manual

14
SA-W2500/W3000/W3800
SECTION 3
ELECTRICAL PARTS LIST
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
AUS : Australian model
A-1223-622-A INPUT CONTROL BOARD, COMPLETE
(W2500: US, CND, TW)
A-1223-645-A INPUT CONTROL BOARD, COMPLETE
(W3000: US, CND)
A-1223-654-A INPUT CONTROL BOARD, COMPLETE
(W3800: US, CND)
A-1223-664-A INPUT CONTROL BOARD, COMPLETE
(W2500: AEP, UK, SP, MY, AUS, KR, TH)
A-1223-685-A INPUT CONTROL BOARD, COMPLETE
(W3000: SP, MY, AUS, KR, TH)
A-1223-695-A INPUT CONTROL BOARD, COMPLETE
(W3800: AEP, SP, MY, AUS)
A-1223-703-A INPUT CONTROL BOARD, COMPLETE
(W2500: E51)
A-1223-709-A INPUT CONTROL BOARD, COMPLETE
(W3000: E51)
A-1223-715-A INPUT CONTROL BOARD, COMPLETE
(W3800: E51)
*****************************
< CAPACITOR >
C102 1-102-978-00 CERAMIC 220PF 5% 50V
C103 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-130-483-00 MYLAR 0.01uF 5% 50V
C106 1-130-483-00 MYLAR 0.01uF 5% 50V
C107 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C108 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C109 1-126-964-11 ELECT 10uF 20% 50V
C110 1-136-175-00 MYLAR 0.68uF 5% 50V
(W2500)
C110 1-137-190-91 FILM 0.22uF 5% 50V
(W3000)
C110 1-136-175-00 FILM 0.68uF 5% 50V
(W3800)
C111 1-136-156-00 FILM 0.018uF 5% 50V
(W3800)
C111 1-136-157-00 FILM 0.022uF 5% 50V
(W2500)
C111 1-136-162-00 FILM 0.056uF 5% 50V
(W3000)
C112 1-130-495-00 FILM 0.1uF 5% 50V
(W3800)
C112 1-136-497-81 FILM 0.1uF 5% 50V
(W3000)
C112 1-137-190-91 FILM 0.22uF 5% 50V
(W2500)
C113 1-130-495-00 FILM 0.1uF 5% 50V
(W3800)
C113 1-136-497-81 FILM 0.1uF 5% 50V
(W3000)
C113 1-137-190-91 FILM 0.22uF 5% 50V
(W2500)
C114 1-126-964-11 ELECT 10uF 20% 50V
C115 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C116 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C117 1-126-964-11 ELECT 10uF 20% 50V
C201 1-126-160-11 ELECT 1uF 20% 50V
C202 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C203 1-126-160-11 ELECT 1uF 20% 50V
C204 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C205 1-126-160-11 ELECT 1uF 20% 50V
C206 1-126-933-11 ELECT 100uF 20% 16V
C207 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C301 1-126-933-11 ELECT 100uF 20% 16V
C302 1-126-933-11 ELECT 100uF 20% 16V
C303 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C304 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C305 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C306 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C307 1-126-964-11 ELECT 10uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C401 1-126-964-11 ELECT 10uF 20% 50V
C402 1-126-964-11 ELECT 10uF 20% 50V
C403 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C404 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C405 1-104-661-91 ELECT 330uF 20% 16V
C406 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C407 1-126-934-11 ELECT 220uF 20% 16V
C408 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C412 1-126-916-11 ELECT 1000uF 20% 6.3V
C430 1-104-658-91 ELECT 100uF 20% 10V
C902 1-117-703-11 CERAMIC 0.0047uF 250V
< CONNECTOR >
CNP402 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
* CNP903 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P (E51)
* CNP904 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP905 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D101 8-719-404-50 DIODE MA111-TX
D102 8-719-404-50 DIODE MA111-TX
D103 8-719-404-50 DIODE MA111-TX
D104 8-719-404-50 DIODE MA111-TX
D301 8-719-083-83 DIODE UDZS-TE17-15B
D302 8-719-083-83 DIODE UDZS-TE17-15B
D401 8-719-404-50 DIODE MA111-TX
D402 8-719-404-50 DIODE MA111-TX
D403 8-719-404-50 DIODE MA111-TX
D404 8-719-404-50 DIODE MA111-TX
Ver. 1.1
INPUT CONTROL
When indicating parts by reference number,
please include the board.
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0 sont
critiques pour la sécurité.
Ne les remplacer que par une piéce portant le
numéro spécifié.
E51 : Chilean and Peruvian model
KR : Korean model
TH : Thai model
TW : Taiwan model

Sony SA-W2500 Specifications

General

frequency response	28Hz-200Hz
woofer size	25cm
power handling	100W
line level input	1 (Rear)
speaker level input	1 (Rear)
power requirements	120V AC, 60Hz
power consumption (in operation)	70W
power consumption (in standby)	less than 0.3W

Weight and Dimensions

weight	10kg
measurements	290 x 350 x 391mm
