HT-CT290/CT291
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISP CHUKEI MAIN
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
E3 : 240 V AC area in E model
E12 : 220-240 V AC area in E model
EA : Saudi Arabia model
LA9 : Latin-American model
RU : Russian Model
SP : Singapore model
TH : Thai model
DISP CHUKEI BOARD
*****************
When the DISP CHUKEI board is defective, replace the DISPLAY ASSY
(SER
VICE) (Ref. No. 102).
*************************************************************
0 A-2165-313-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: US, CND)
0 A-2165-410-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: AEP)
0 A-2165-421-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: UK)
0 A-2165-431-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: SP)
0 A-2165-441-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: E12)
0 A-2165-506-A MAIN BOARD, COMPLETE (for SERVICE)
(for White model) (CT291: AEP)
0 A-2165-518-A MAIN BOARD, COMPLETE (for SERVICE)
(for White model) (CT291: UK)
0 A-2166-004-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: LA9)
0 A-2180-390-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: RU)
0 A-2180-412-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: EA)
0 A-2180-418-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: AUS)
0 A-2180-424-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: TH)
0 A-2180-430-A MAIN BOARD, COMPLETE (for SERVICE)
(for Black model) (CT290: E3)
0 A-2180-440-A MAIN BOARD, COMPLETE (for SERVICE)
(for White model) (CT291: RU)
0 A-2180-542-A MAIN BOARD, COMPLETE (for SERVICE)
(for White model) (CT290: LA9)
0 A-2180-548-A MAIN BOARD, COMPLETE (for SERVICE)
(for White model) (CT290: SP)
0 A-2180-567-A MAIN BOARD, COMPLETE (for SERVICE)
(for White model) (CT290: EA)
0 A-2180-573-A MAIN BOARD, COMPLETE (for SERVICE)
(for White model) (CT290: TH)
*********************
< CAPACITOR >
C3296 1-137-765-21 ELECT CHIP 47uF 20% 16V
< CONNECTOR >
CN3001 1-843-486-31 HDMI CONNECTOR (HDMI OUT TV (ARC))
< DIODE >
D3200 6-503-735-01 DI BZT52H-C4V3
< FERRITE BEAD >
FB2005 1-481-648-21 FERRITE, EMI (SMD)
< IC >
IC1000 6-723-247-01 IC TAS5534DGGR-S
IC1001 6-723-248-01 IC TAS5614LA-S
IC3000 6-720-030-01 IC TPS2065CDBVR
IC3200 6-718-999-01 IC MM1839A50NRE
IC3207 6-723-083-01 IC S-1212BC0-E6T1U
IC3209 6-720-407-01 IC BD00HA3WEFJ
< TRANSISTOR >
Q3204 6-551-248-01 TRANSISTOR NTJS3151PT1G
*************************************************************
A-2143-282-A TOUCH BOARD, COMPLETE
**********************
< CAPACITOR >
C4000 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
< CONNECTOR >
CN4001 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
Note: When the complete MAIN board is replaced, refer to “NOTE
OF REPLACING THE IC1001 ON THE MAIN BOARD AND
THE COMPLETE MAIN BOARD” and “NOTES ON THE
WIRELESS CONNECTION (LINK) AFTER REPAIRS ARE
COMPLETE” on page 5.
TOUCH
To Next Page
