2-2

2 MA-370 board with

mechanism deck

1 Six screws

(Sumitite (B3) +BV)

2-3. REAR PANEL

Hooks

2 Rear panel

(Engaged by the seven hooks)

1 POWER code stoppe

2-4. MA-370 BOARD

Default Chapter1
- Specifications1
- Table of Contents3
Service Note5
- Error Code Indication5
1 General7
2 Disassembly35
3 Block Diagrams41
4 Printed Wiring Boards and Schematic Diagrams47
- Frame Schematic Diagram49
5 Interface, IC Pin Function Description67
6 Adjustments71
7 Repair Parts List77
