7-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
* A-6794-713-A DI-74 BOARD, COMPLETE
(LX4/LX5/LX6S/LX7S)
*********************
* A-6794-730-A DI-74S BOARD, COMPLETE (N70/N80/LX8S)
**********************
* A-6794-726-A DI-74V BOARD, COMPLETE (AX20/N60)
**********************
* A-6794-763-A DI-74VMX BOARD, COMPLETE (N60U)
*************************
(Ref. No.:1,000 Series)
< SWITCH >
S901 1-418-156-11 ENCODER, ROTARYRY (DIAL TIMER)
************************************************************
* A-6794-718-A DM-89 BOARD, COMPLETE (N70/N80/LX8S)
*********************
(Ref. No.:2,000 Series)
< CONNECTOR >
CN471 1-506-484-11 PIN, CONNECTOR 5P
< JUMPER RESISTOR >
JR465 1-216-295-00 METAL CHIP 0 5% 1/10W
< RESISTOR >
R464 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R465 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R467 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R468 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R469 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R470 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R474 1-216-013-00 METAL CHIP 33 5% 1/10W
< SWITCH >
S462 1-762-196-21 SWITCH, TACT (EJECT)
S463 1-762-196-21 SWITCH, TACT (REC)
S466 1-762-196-21 SWITCH, TACT (REW)
S467 1-762-196-21 SWITCH, TACT (STOP)
S468 1-762-196-21 SWITCH, TACT (PLAY)
S469 1-762-196-21 SWITCH, TACT (FF)
S472 1-762-196-21 SWITCH, TACT (PAUSE)
************************************************************
* A-6794-715-A JK-178H BOARD, COMPLETE (LX6S/LX7S)
***********************
* A-6794-725-A JK-178HV BOARD, COMPLETE
(AX10/AX20/N50/N60)
************************
* A-6794-762-A JK-178HVMX BOARD, COMPLETE (N60U)
***************************
* A-6794-714-A JK-178M BOARD, COMPLETE (LX4/LX5)
***********************
(Ref. No.:3,000 Series)
< CAPACITOR >
C803 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C805 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(AX10/AX20/N50/N60/LX6S/LX7S)
C806 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN801 1-506-484-11 PIN, CONNECTOR 5P
(AX10/AX20/N50/N60/LX6S/LX7S)
CN801 1-506-483-21 PIN, CONNECTOR 4P (LX4/LX5)
* CN802 1-568-941-11 PIN, CONNECTOR 3P(LINE 2 IN(VIDEO/AUDIO))
< DIODE >
D801 8-719-067-40 DIODE STZ6.8N-T146
D802 8-719-067-40 DIODE STZ6.8N-T146
D803 8-719-422-37 DIODE MA8051
D804 8-719-067-40 DIODE STZ6.8N-T146
< JACK >
J801 1-580-845-11 JACK, PIN 3P (LINE 2 IN(VIDEO/AUDIO))
(AX10/AX20/N50/N60/LX6S/LX7S)
J801 1-785-622-11 JACK, PIN 2P (LINE 2 IN(VIDEO/AUDIO))
(LX4/LX5)
J801 1-770-021-11 JACK, PIN 3P (LINE 2 IN(VIDEO/AUDIO))
(AX10/AX20/N50/N60/LX6S/LX7S)
< JUMPER RESISTOR >
JS801 1-216-295-00 METAL CHIP 0 5% 1/10W
(LX4/LX5)
< RESISTOR >
R801 1-216-295-00 METAL CHIP 0 5% 1/10W
R802 1-216-295-00 METAL CHIP 0 5% 1/10W
(AX10/AX20/N50/N60/LX6S/LX7S)
R803 1-216-022-00 METAL CHIP 75 5% 1/10W
R804 1-216-013-00 METAL CHIP 33 5% 1/10W
R805 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
DI-74 DM-89 JK-178
To Next Page
