15
NSR-500
NSR-S20
(2TB)
NSR-S20
(Without HDD)
NSR-S10
(1TB)
NSR-S10
(Without HDD)
Video/Recording
Number of cameras supported Max. 16
(Max. 24ch w/NSBK-CL05) (IP/Analog total)
Max. 8 Max. 4
Number of analog cameras Option (NSBK-EB05) No No
Video compression (IP camera) H.264 / MPEG-4 / JPEG H.264/MPEG-4/JPEG H.264/MPEG-4/JPEG
Video compression (Analog camera) Option (NSBK-EB05) No No
Recording frame rate 480fps
(at H.264, Full-HD, 4Mbps)
120fps
(at H.264, Full-HD, 4Mbps)
60fps
(at H.264, Full-HD, 4Mbps)
Hard disk drives (Physical capacity) Up to 12TB (2TB x 6) 2TB No HDD 1TB (1TB x1) No HDD
Hard disk drives (RAID level) RAID 0, 1, 10 (1+0), 5, 5+hot spare No No
Optical disc drive No No No
Expansion storage iSCSI storage (max. 16TB) e-SATA storage (max. 4TB) e-SATA storage (max. 4TB)
Video Output
Monitor OUT 1 Analog RGB
(D-sub 15-pin) x 1
Analog RGB (D-sub 15-pin) x 1 Analog RGB (D-sub 15-pin) x 1
Monitor OUT 2 No No No
Audio Output
Audio OUT Stereo mini jack x 1 Terminal connecter x 1 Terminal connecter x 1
Sensor Input/Alarm Output
Sensor input Compatible with DC3.3V to 24V,
photo coupler input x 8 (insulated from main unit)
Terminal connecter x 4 Terminal connecter x 4
Alarm output Max. DC 24V/ 1A, mechanical relay output x 8 (insulated from main unit) Terminal connector x 1 Terminal connector x 1
Other Interfaces
Ethernet 1000BASE-T/100BASE-TX/10BASE-T x 2 1000BASE-T/100BASE-TX/10BASE-T x 2 1000BASE-T/100BASE-TX/10BASE-T x 2
USB USB2.0 x 2 (Front), USB2.0 x 2 (Rear) USB2.0 x 1 (Front), USB2.0 x 2 (Rear) USB2.0 x 1 (Front), USB2.0 x 2 (Rear)
Serial interface (for UPS) RS-232C : D-sub 9-pin x 1 No No
Serial interface
(for analog camera control)
RS-232C : D-sub 9pin x 1,
RS-422/485 x 1 (when installing NSBK-EB05) *
2
No No
General
Dimensions (W x H x D) 17 3/8 x 3 1/2 x 15 1/2 inches (440 x 89 x 392mm)
* excluding protrusions
9 3/4 x 2 1/8 x 6 3/8 inches (245 x 53 x 160mm)
* excluding protrusions
9 3/4 x 2 1/8 x 6 3/8 inches (245 x 53 x 160mm)
* excluding protrusions
Weight Approx. 20 lb 12 oz
(9.4Kg)
(Without HDD model)
Approx. 3 lb 1oz
(1.4 Kg)
Approx. 1 lb 12oz
(0.8 Kg)
Approx. 3 lb 1oz
(1.4 Kg)
Approx. 1 lb 12oz
(0.8 Kg)
Power requirements 100V to 127V AC / 200V to 240V (50/60Hz) DC 12V (AC adapter: 100V to 240V AC, 50/60Hz) DC 12V (AC adapter: 100V to 240V AC, 50/60Hz)
Power consumption max. 250W
(100-240V 3.5-1.5A)
Approx. 36W Approx. 36W
Operating temperature 41 to 104˚F (5 to 40˚C) 41 to 104˚F (5 to 40˚C) 41 to 104˚F (5 to 40˚C)
Operation humidity 20 to 80% (no condensing) 20% to 80% 20% to 80%
Optional accessories NSBK-DH05, NSBK-EB05, NSBK-CL05, NSBK-HS05:01, NSBK-HS05:02,
RM-NS1000
- -
Network Surveillance Recording Servers
*1: More than one connector cannot be used at a time. *2: VISCA and Pelco-D are supported. and recorded. So display out is used for making settings.
The NSR-500 Series complies with UL60950-1
