IP Rapid Dome and PTZ Cameras
P/T/Z: Pan/Tilt/Zoom
E Series
Model name
SNC-ER580 SNC-EP580 SNC-ER550 SNC-EP550 SNC-RH164 SNC-RH124
Video compression format
H.264/MPEG-4/JPEG
Codec streaming
capability
Dual streaming (Any combination with H.264/MPEG-4/JPEG, including multiple streams of the same format)
Computer display format
(
*
1)
(
*
1)
(
*
1)
(
*
1)
Maximum resolution
1920 x 1080 1920 x 1080
1280 x 720 1280 x 720
1280 x 720
1280 x 720
Outdoor use/
Ingress protection
No No No No
Yes/IP66
No
Vandal resistant
No No No No IK10 No
Horizontal viewing angle
55.4° to 2.9° 55.4° to 2.9° 55.9° to 2.1° 55.9° to 2.1° 50° to 5.4° 50° to 5.4°
Zoom ratio
20X optical zoom 20X optical zoom 28X optical zoom 28X optical zoom 10x optical zoom 10x optical zoom
Focal length
f=4.7 to 94 mm f=4.7 to 94 mm f=3.5 to 98 mm f=3.5 to 98 mm f=5.1 to 51 mm f=5.1 to 51 mm
Image device
1/2.8-type Exmor CMOS sensor
1/2.8-type Exmor CMOS sensor 1/4-type Exmor CMOS sensor 1/4-type Exmor CMOS sensor 1/3-type HD CMOS
sensor
1/3-type HD CMOS
sensor
Minimum illumination
Color: 1.7 lx, B/W: 0.07 lx
(F1.6, shutter 1/30sec,
AGC ON, 50IRE[IP])
Color: 1.7 lx, B/W: 0.07 lx
(F1.6, shutter 1/30sec,
AGC ON, 50IRE[IP])
Color: 2.0 lx (Tentative) Color: 2.0 lx (Tentative) Color: 2.1 lx, B/W: 0.19 lx
(XDNR ON, VE ON,
Slow Shutter OFF, 50 IRE [IP])
Color: 1.9 lx, B/W: 0.17 lx
(XDNR ON, VE ON,
Slow Shutter OFF, 50 IRE [IP])
Maximum frame rate
30 fps H.264 at 1920 x 1080;
20 fps MPEG-4 at 1920 x 1080;
16 fps JPEG at 1920 x 1080
30 fps H.264 at 1920 x 1080;
20 fps MPEG-4 at 1920 x 1080;
16 fps JPEG at 1920 x 1080
30 fps H.264/
MPEG-4/JPEG
30 fps H.264/
MPEG-4/JPEG
30 fps H.264/
MPEG-4/JPEG at 1280 x 720
30 fps H.264/
MPEG-4/JPEG at 1280 x 720
Day/Night
Day/Night Day/Night Day/Night Day/Night Day/Night Day/Night
Wide-D
Visibility Enhancer (VE)
Yes/ Yes/ Yes/ Yes/
Yes/
VE
Yes/
VE
Noise reduction
Yes Yes Yes Yes XDNR XDNR
Card slot(s)
SD card x1 SD card x1 SD card x1 SD card x1 CF card x1 CF card x1
Wireless capability
No No No No Yes (option) Yes (option)
Composite video output
No No No No Yes Yes
DEPA (Intelligence)
Audio Capability
No No No No Yes Yes
ONVIF software
Rapid Dome or PTZ
Rapid Dome
PTZ Rapid Dome PTZ Rapid Dome Rapid Dome
Pan angle
360 degrees endless rotation 340 degrees 360 degrees endless rotation 340 degrees 360° endless 360° endless
Tilt angle
-105° to +105° (210° tilt) -15° to +90° -105° to +105° (210° tilt) -15° to +90° -105° to +105° (210° tilt) -105° to +105° (210° tilt)
Quick Release mechanism
No No No No Quick Release Quick Release
Power requirement
AC 24 V, HPoE (Class 4) AC 24 V, HPoE (Class 4) AC 24 V, HPoE (Class 4) AC 24 V, HPoE (Class 4) AC 24 V AC 24 V, DC 12 V, HPoE (Class 4)
Power consumption
25 W max. 25 W max. 25 W max. 25 W max. 80 W max. 25 W max.
Dimensions
ø 5 7/8 x 7 5/8 inches
(147.4 x 190.9 mm )
ø 5 7/8 x 7 5/8 inches
(147.4 x 190.9 mm)
ø 5 7/8 x 7 5/8 inches
(147.4 x 190.9 mm)
ø 5 7/8 x 7 5/8 inches
(147.4 x 190.9 mm)
ø 9 3/8 x 13 5/8 inches
(238 x 346 mm)
ø 6 1/8 x 9 inches
(154 x 226 mm)
(*1)
Definition of HD: More than 720p with H.264 streaming capability of more than 30 fps.
All cameras in this sheet comply with UL2044.
