5
Operating Multiple Cameras Using the IP Remote Controller
What you can do with this system
You can operate up to 7 cameras with daisy chain connection using the IP remote controller (not supplied).
System Configuration
• Only RS-232 connection is available for VISCA CONTROL.
• You need to match the communication speed between the camera and the IP remote controller.
• Only one camera at a time can be displayed on the computer.
• You cannot use the RS-232 connections when using the LAN connection.
• The specified frame rate may not be output when communicating via a USB3.0 hub.
Notes
,
Computer
Video signal
Remote control (VISCA) signal
Signal flow
IP Remote Controller (not supplied)
USB3.0 hub
To Next Page
