Command List (7/8)
Number in ( ) is MENU display values.
*
Refer to the section of the Pan/Tilt Position of VISCA Command Setting Values.
Command Set Command Command Packet Comments
PAN TILT PAN TILT DRIVE Up 8x 01 06 01 vv ww 03 01
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
Down 8x 01 06 01 vv ww 03 02
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
Left 8x 01 06 01 vv ww 01 03
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
Right 8x 01 06 01 vv ww 02 03
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
UpLeft 8x 01 06 01 vv ww 01 01
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
UpRight 8x 01 06 01 vv ww 02 01
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
DownLeft 8x 01 06 01 vv ww 01 02
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
DownRight 8x 01 06 01 vv ww 02 02
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
Stop 8x 01 06 01 vv ww 03 03
FF
vv: Pan speed 01 (Slow) - 18 (Fast)
ww: Tilt speed 01 (Slow) - 17 (Fast)
ABS
(Absolute
Position)
8x 01 06 02 vv 00 0p 0p
0p 0p 0t 0t 0t 0t FF
vv: Pan-Tilt speed 01 (Slow) - 18 (Fast)
pppp: Pan-coordinate*
tttt: Tilt-coordinate*
REL (Relative
Position)
8x 01 06 03 vv 00 0p 0p
0p 0p 0t 0t 0t 0t FF
vv: Pan-Tilt speed 01 (Slow) - 18 (Fast)
pppp: Pan-shift amount*
tttt: Tilt-shift amount*
Home 8x 01 06 04 FF
Reset 8x 01 06 05 FF
RAMP CURVE - 8x 01 06 31 0p FF p: 1=Sharpness
PAN-TILT SLOW On/Off 8x 01 06 44 0p FF p: 2=On, 3=Off
PAN TILT LIMIT Limit Set 8x 01 06 07 00 0q 0p 0p
0p 0p 0t 0t 0t 0t FF
q: Position (1=UpRight, 0=DownLeft)
For pppp and tttt, refer to the section of the
Pan/Tilt Position of VISCA Command
Setting Values
Limit Clear 8x 01 06 07 01 0q 07 0F
0F 0F 07 0F 0F 0F FF
q: Position (1=UpRight, 0=DownLeft)
