8
GB
Getting Started
1: Check how to hookup your components
Steps 1a through 1c beginning on page 10 describe how to hook up your components to this receiver.
Before you begin, refer to “Connectable components” below for the pages which describe how to
connect each component.
After hooking up all your components, proceed to “2: Connecting the antennas” (page 17).
Connectable components
Component to be connected Page
DVD/LD player
With digital audio output*
1
10–11
With multi-channel audio output*
2
13–14
With analog audio output only*
3
10–11
TV
With component video input*
4
11 or 14
With S-Video or composite video input only 16
Satellite tuner
With digital audio output*
1
10–11
With analog audio output only*
3
10–11
CD/Super Audio CD player
With digital audio output*
1
12
With multi-channel audio output*
2
13
With analog audio output only*
3
15
MD/DAT deck
With digital audio output*
1
12
With analog audio output only*
3
15
Cassette deck, analog disc turntable 15
Multi-channel decoder 13
VCR, video camera, video game, etc. 16
*
1
Model with a DIGITAL OPTICAL OUTPUT or DIGITAL COAXIAL OUTPUT connector, etc.
*
2
Model with a MULTI CH OUTPUT connectors, etc. This connection is used to output the audio decoded by the
component’s internal multi-channel decoder through this receiver.
*
3
Model equipped only with AUDIO OUT L/R jacks, etc.
*
4
Model with component video (Y, B-Y, R-Y) input jacks.
To Next Page
