Sony STR-DG710 Service Manual

73
STR-DG710
Ref. No. Part No. Description Remark
R1511 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1512 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1513 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1514 1-216-809-11 METAL CHIP 100 5% 1/10W
R1516 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1523 1-216-813-11 METAL CHIP 220 5% 1/10W
R1530 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1531 1-216-809-11 METAL CHIP 100 5% 1/10W
R1541 1-216-813-11 METAL CHIP 220 5% 1/10W
R1555 1-216-813-11 METAL CHIP 220 5% 1/10W
R1556 1-216-809-11 METAL CHIP 100 5% 1/10W
R1557 1-216-813-11 METAL CHIP 220 5% 1/10W
R1570 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1571 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1572 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1602 1-216-864-11 SHORT CHIP 0
R1635 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1636 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1637 1-216-864-11 SHORT CHIP 0
R1701 1-216-864-11 SHORT CHIP 0
R1702 1-216-813-11 METAL CHIP 220 5% 1/10W
R1703 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1704 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1705 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1707 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1708 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1709 1-216-809-11 METAL CHIP 100 5% 1/10W
R1710 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1711 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1712 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1713 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1714 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1716 1-216-809-11 METAL CHIP 100 5% 1/10W
R1801 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1802 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1804 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1805 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1806 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1807 1-216-809-11 METAL CHIP 100 5% 1/10W
(US,CND)
R1941 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1946 1-216-809-11 METAL CHIP 100 5% 1/10W
R1947 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1948 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1949 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1951 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1952 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1953 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1954 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1960 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1961 1-216-801-11 METAL CHIP 22 5% 1/10W
R1962 1-216-809-11 METAL CHIP 100 5% 1/10W
R1964 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB1500 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1501 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1502 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1503 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1504 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1506 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1507 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
RB1508 1-233-576-11 RES, CHIP NETWORK 100X4 (3216)
< VIBRATOR >
X1101 1-781-893-21 VIBRATOR, CERAMIC (CHIP TYPE) (12.5MHz)
X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
X1502 1-813-276-21 QUARTZ, CRYSTAL (13.9MHz)
*************************************************************
A-1225-205-A DISPLAY BOARD, COMPLETE (US,CND)
A-1225-206-A DISPLAY BOARD, COMPLETE (AEP,UK)
A-1225-207-A DISPLAY BOARD, COMPLETE (MY,SP,TH)
A-1225-208-A DISPLAY BOARD, COMPLETE (AUS)
************************
< CAPACITOR >
C110 1-162-286-31 CERAMIC 220PF 10% 50V
C111 1-162-286-31 CERAMIC 220PF 10% 50V
C112 1-162-286-31 CERAMIC 220PF 10% 50V
C114 1-127-888-11 CERAMIC 0.1uF 10% 50V
C115 1-126-964-11 ELECT 10uF 20% 50V
C144 1-127-888-11 CERAMIC 0.1uF 10% 50V
C145 1-127-888-11 CERAMIC 0.1uF 10% 50V
C147 1-162-286-31 CERAMIC 220PF 10% 50V
C148 1-126-964-11 ELECT 10uF 20% 50V
C149 1-162-286-31 CERAMIC 220PF 10% 50V
C160 1-127-888-11 CERAMIC 0.1uF 10% 50V
C162 1-127-888-11 CERAMIC 0.1uF 10% 50V
C164 1-162-286-31 CERAMIC 220PF 10% 50V
C165 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN104 1-691-746-11 CONNECTOR, BOARD TO BOARD 5P
CNP106 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
CNS101 1-784-780-11 CONNECTOR, FFC 19P
< VACUUM FLUORESCENT DISPLAY >
FL101 1-519-927-11 VACUUM FLUORESCENT DISPLAY
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-243-51 IC TC74ACT08P
IC103 6-600-349-31 IC NJL24H400A (IR)
< RESISTOR >
R101 1-249-409-11 CARBON 220 5% 1/4W
R102 1-249-411-11 CARBON 330 5% 1/4W
R103 1-249-413-11 CARBON 470 5% 1/4W
R104 1-249-415-11 CARBON 680 5% 1/4W
R105 1-247-831-11 CARBON 1K 5% 1/4W
Ref. No. Part No. Description Remark
DIGITAL DISPLAY
Ver. 1.1

Sony STR-DG710 Specifications

General

RMS rated power	600 W
Audio output channels	5.1 channels
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
I/O ports	AV in/out Video in/out HDMI in/out D-Sub DM
Connectivity technology	Wired
Headphone outputs	1
Product color	Black
Dimensions (WxDxH)	430 x 157.5 x 310 mm

Weight and Dimensions

Weight	7800 g
