Getting Started
3b: Connecting the video components
This section describes how to hook up your
components to this receiver. Before you begin,
refer to “Component to be connected” below
for the pages which describe how to connect
each component.
After hooking up all your components,
proceed to “4: Connecting the antennas” (page
32).
Component to be connected
The image quality depends on the connecting
jack. Refer to the illustration that follows.
Select the connection according to the jacks on
your components.
How to hook up your
components
Component Page
TV monitor 25
DVD player/DVD recorder 26
Satellite tuner 28
VCR 29
Camcorder, video game, etc. 29
With HDMI jack 30
Video input/output jack to be
connected
continued
