102
STR-DG910
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* CN202 1-690-880-31 LEAD (WITH CONNECTOR)
< JACK >
J298 1-819-189-11 JACK, PIN 3P (VIDEO 3 IN/PORTABLE AV IN
VIDEO,AUDIO)
< RESISTOR >
R298 1-216-821-11 METAL CHIP 1K 5% 1/10W
R299 1-216-821-11 METAL CHIP 1K 5% 1/10W
*************************************************************
A-1222-793-A XM BOARD, COMPLETE (US,CND)
*******************
< CAPACITOR >
C101 1-137-649-31 ELECT 220uF 20% 10V
C102 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-112-100-11 ELECT 10uF 20% 50V
C105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C107 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-216-864-11 SHORT CHIP 0
C113 1-126-964-11 ELECT 10uF 20% 50V
C114 1-216-864-11 SHORT CHIP 0
C115 1-216-864-11 SHORT CHIP 0
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-216-864-11 SHORT CHIP 0
C118 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C119 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C120 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C121 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C122 1-112-100-11 ELECT 10uF 20% 50V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C125 1-112-100-11 ELECT 10uF 20% 50V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C128 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C129 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C132 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C133 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C134 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C136 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C137 1-126-964-11 ELECT 10uF 20% 50V
C138 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C139 1-126-964-11 ELECT 10uF 20% 50V
C140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C142 1-126-964-11 ELECT 10uF 20% 50V
C143 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C144 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C145 1-126-933-11 ELECT 100uF 20% 16V
C153 1-126-933-11 ELECT 100uF 20% 16V
C157 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C159 1-137-649-31 ELECT 220uF 20% 10V
C161 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C163 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C164 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C165 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C166 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C167 1-216-864-11 SHORT CHIP 0
C168 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C169 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P
CN102 1-784-766-11 CONNECTOR, FFC 5P
CNP103 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D101 6-500-462-01 DIODE NSAD500F-T1B
D103 8-719-083-02 DIODE KDS160-RTK
< FERRITE BEAD >
FB101 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB104 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC101 6-705-468-01 IC BA33BC0FP-E2
IC102 6-709-251-01 IC F2602E-01-TR
IC104 8-759-710-97 IC NJM4565M-D
IC105 6-707-111-01 IC PCM1753DBQR
IC106 6-707-802-01 IC BA00CC0WT(-V5)
IC107 6-705-469-01 IC BA50BC0FP-E2
< CONNECTOR >
J101 1-793-642-21 CONNECTOR (USB) (4P), SQUARE (XM)
< JUMPER RESISTOR >
JR101 1-216-296-11 SHORT CHIP 0
L101 1-216-295-11 SHORT CHIP 0
L102 1-216-295-11 SHORT CHIP 0
< TRANSISTOR >
Q105 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q106 8-729-140-93 TRANSISTOR 2SB733-34
< RESISTOR >
R101 1-216-845-11 METAL CHIP 100K 5% 1/10W
R102 1-216-845-11 METAL CHIP 100K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-841-11 METAL CHIP 47K 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-833-11 METAL CHIP 10K 5% 1/10W
R113 1-216-864-11 SHORT CHIP 0
