STR-DG910
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC SELECT BOARD (E2)
****************
1-533-217-41 HOLDER, FUSE
< CONNECTOR >
* CNP910 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< SWITCH >
0S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)
*************************************************************
DCAC BOARD
***********
< CAPACITOR >
C2500 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2502 1-126-795-11 ELECT 10uF 20% 50V
C2503 1-126-795-11 ELECT 10uF 20% 50V
C2504 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2505 1-126-795-11 ELECT 10uF 20% 50V
C2506 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2513 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C2514 1-119-772-11 ELECT 47uF 20% 35V
C2515 1-126-795-11 ELECT 10uF 20% 50V
C2516 1-126-795-11 ELECT 10uF 20% 50V
C2517 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2518 1-104-957-11 ELECT 47uF 20% 25V
C2519 1-126-160-11 ELECT 1uF 20% 50V
C2520 1-126-795-11 ELECT 10uF 20% 50V
C2521 1-126-795-11 ELECT 10uF 20% 50V
C2522 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2523 1-104-957-11 ELECT 47uF 20% 25V
C2524 1-119-772-11 ELECT 47uF 20% 35V
C2525 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C2526 1-126-795-11 ELECT 10uF 20% 50V
C2528 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C2529 1-119-772-11 ELECT 47uF 20% 35V
C2530 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN711 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D2500 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB2500 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC2501 8-759-825-56 IC NJM2173AV(TE2)
IC2502 6-705-468-01 IC BA33BC0FP-E2
< JACK >
J2500 1-820-056-11 JACK (SMALL TYPE) (AUTO CAL MIC)
< TRANSISTOR >
Q2500 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
< RESISTOR >
R2501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2503 1-216-849-11 METAL CHIP 220K 5% 1/10W
R2504 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2506 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2507 1-216-843-11 METAL CHIP 68K 5% 1/10W
R2508 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2513 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2514 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2518 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2519 1-216-821-11 METAL CHIP 1K 5% 1/10W
< LEAD WIRE >
* W2500 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
DCDC BOARD
***********
1-533-217-41 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C4002 1-128-549-11 ELECT 3300uF 20% 35V
C4003 1-115-814-11 ELECT 0.001F 20% 35V
C4004 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C4005 1-128-950-31 ELECT 1000uF 20% 16V
C4006 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
•Abbreviation
E2 : AC 120 V area in E model
CND : Canadian model
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant le
numéro spécifié.
When indicating parts by reference
number, please include the board.
The components identified by mark 9 contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifiés par la marque 9
contiennent des informations confidentielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé et/
ou réparé.
