58
STR-KS1200
SECTION 6
EXPLODED VIEWS
1 3-378-435-01 CUSHION, SARANET
2 3-701-748-00 CLAMP
3 1-457-369-11 CORE, FERRITE
4 3-703-244-00 CORD BUSH (2104)
0 5 1-777-071-83 CORD, POWER
9 6 A-1253-210-A HDMI RE BOARD, COMPLETE (for SERVICE)
7 3-070-883-31 SCREW, TAPPING
8 2-897-876-21 CASE (SL07)
9 1-828-349-11 WIRE (FLAT TYPE) (17 CORE)
10 3-655-653-11 BAND (TAITON), BINDING
TP700 1-775-377-51 LEAD (WITH CONNECTOR)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Color Indication of Appearance Parts Ex-
ample:
KNOB, BALANCE (WHITE) . . . (RED)
R R
Parts of Color Cabinet’s Color
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• The mechanical parts with no reference
number in the exploded views are not sup-
plied.
• Accessory are given in the last of the elec-
trical parts list.
6-1. CASE, HDMI RE BOARD SECTION
1
#1
#1
#1
#1
#1
#1
#2
not supplied
MAIN board section
TP700
front panel section
6
7
7
8
9
2
4
5
3
10
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Note: If wire (fl at type) is replaced, install it after bending
it in the same form as that before replacement.
