STR-KS1200
SECTION 7
ELECTRICAL PARTS LIST
DCAC (1200) BOARD
****************
< CAPACITOR >
C2800 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2802 1-124-261-00 ELECT 10uF 20% 50V
C2803 1-124-261-00 ELECT 10uF 20% 50V
C2804 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2805 1-124-261-00 ELECT 10uF 20% 50V
C2806 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2813 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2814 1-119-772-11 ELECT 47uF 20% 35V
C2815 1-124-261-00 ELECT 10uF 20% 50V
C2816 1-124-261-00 ELECT 10uF 20% 50V
C2817 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2818 1-104-957-11 ELECT 47uF 20% 25V
C2819 1-126-160-11 ELECT 1uF 20% 50V
C2820 1-124-261-00 ELECT 10uF 20% 50V
C2821 1-124-261-00 ELECT 10uF 20% 50V
C2822 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C2823 1-104-957-11 ELECT 47uF 20% 25V
C2824 1-119-772-11 ELECT 47uF 20% 35V
C2825 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2826 1-124-261-00 ELECT 10uF 20% 50V
C2828 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C2829 1-119-772-11 ELECT 47uF 20% 35V
C2830 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< DIODE >
D2800 8-719-404-50 DIODE MA111-TX
< GROUND TERMINAL >
EB2800 1-537-738-21 TERMINAL, GROUND
< FERRITE BEAD >
FB2800 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC2801 8-759-825-56 IC NJM2173AV (TE2)
IC2802 6-705-468-01 IC BA33BC0FP-E2
< JACK >
J2800 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC)
< TRANSISTOR >
Q2800 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
< RESISTOR >
R2801 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2803 1-216-849-11 METAL CHIP 220K 5% 1/10W
R2804 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2806 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2807 1-216-843-11 METAL CHIP 68K 5% 1/10W
R2808 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2813 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2814 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2818 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2819 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
A-1227-752-A DISPLAY BOARD, COMPLETE
***********************
4-246-476-01 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C700 1-126-795-11 ELECT 10uF 20% 50V
C701 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C702 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C703 1-126-795-11 ELECT 10uF 20% 50V
C704 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C705 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C706 1-126-795-11 ELECT 10uF 20% 50V
C707 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C708 1-126-795-11 ELECT 10uF 20% 50V
C709 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C711 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C750 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C751 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C752 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C753 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C754 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C755 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C756 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C757 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C758 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C759 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C760 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C761 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C762 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DCAC (1200)
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
DISPLAY
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
