Sony VPL-FHZ66 User Manual

58
INPUT D HDBaseT terminal: RJ45
HDBaseT transmittable signal: HDMI (Video, Audio),
RS-232C, Ethernet (100BASE-TX)
HDBaseT LAN cable: STP type (CAT5e or higher,
straight, not supplied), Maximum length: 100 m
VIDEO IN Video input terminal: BNC, 1 Vp-p ± 2 dB, sync
negative, 75 ohms terminated
Audio input terminal: Shared with INPUT A
OUTPUT A MONITOR output terminal: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: HD, VD 4 V (open),
1 Vp-p (75 ohms), positive/negative
Audio output terminal: Stereo mini jack, stereo,
1 Vrms (maximum volume, when inputting 500 mVrms),
output impedance 5 kilohms
OUTPUT B DVI-D output terminal: DVI-D 24-pin (Single link),
DVI 1.0 compliant, non-HDCP compliant
Control signal
input/output
RS-232C terminal: D-Sub 9 pin male
LAN terminal: RJ45, 10BASE-T/100BASE-TX
CONTROL S input terminal (DC power supply):
Stereo mini jack, 5 Vp-p, Plug in power DC 5 V
Operating
temperature/
Operating
humidity
0 °C to 40 °C (32 °F to 104 °F)/20% to 80% (no
condensation)
Storage
temperature/
Storage humidity
–10 °C to +60 °C (14 °F to +140 °F)/ 20% to 80% (no
condensation)
Power required VPL-FHZ66/FWZ65: AC 100 V to 240 V, 5.5 A to
2.3 A, 50/60 Hz
VPL-FHZ61/FHZ58/FWZ60: AC 100 V to 240 V,
4.5 A to 1.9 A, 50/60 Hz
Power
consumption
AC 100 V to
120 V
VPL-FHZ66: 515 W
VPL-FHZ61: 420 W
VPL-FHZ58: 367 W
VPL-FWZ65: 464 W
VPL-FWZ60: 383 W
AC 220 V to
240 V
VPL-FHZ66: 497 W
VPL-FHZ61: 408 W
VPL-FHZ58: 352 W
VPL-FWZ65: 453 W
VPL-FWZ60: 372 W
Power
consumption
(Standby Mode)
AC 100 V to
120 V
0.50 W (when “Standby Mode” is set to “Low”)
AC 220 V to
240 V
0.50 W (when “Standby Mode” is set to “Low”)
