Sony VPL-HW45 User Manual

GB
14
c Adjust the focus using the focus
ring.
Lens adjustment window (test pattern)
Focus ring
2.35:1
4:3
1.85:1
The dashed lines show the screen sizes of each
aspect ratio.
For more information, refer to
“Connections and Preparations” in the
Operating Instructions contained in the
supplied CD-ROM.

Sony VPL-HW45 Specifications

General

Display Technology	SXRD
Resolution	1920 x 1080
Brightness	1800 lumens
Contrast Ratio	120, 000:1
Zoom Ratio	1.6x
Lens Shift	Vertical: ±71%, Horizontal: ±25%
3D	Yes
Dimensions	407.4 x 179.2 x 463.9 mm
Lamp Life	6000 hours
Inputs	2 x HDMI
Weight	9 kg
Lens Throw Ratio	1.36 - 2.16:1
Throw Ratio	1.36:1 - 2.16:1
Projection Size	40" to 300"
Lamp Type	Ultra high pressure mercury lamp
