SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
WM-GX221
•Abbreviation
5E : E model with the indication of the
country of origin.
9E : E model without the indication of the
country of origin.
CH : Chinese model
CND : Canadian model
EA : Saudi Arabia model
TW : Taiwan model
* A-3021-657-A MAIN BOARD, COMPLETE (EA)
* A-3021-658-A MAIN BOARD, COMPLETE (US, CND)
* A-3021-667-A MAIN BOARD, COMPLETE (E, 9E, CH, TW)
* A-3021-668-A MAIN BOARD, COMPLETE (5E)
************************
3-237-135-01 GEAR (A)
3-237-149-01 TERMINAL (-), BATTERY
3-237-150-01 TERMINAL (+), BATTERY
7-627-552-08 SCREW,PRECISION +P 1.7X2.5
< CAPACITOR >
C1 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(US, CND, 5E)
C2 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT US, CND, 5E)
C3 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5 1-162-937-11 CERAMIC CHIP 6PF 0.5PF 50V
C7 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C9 1-162-997-11 CERAMIC CHIP 10PF 0.5PF 50V (EA)
C9 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(EXCEPT EA)
C10 1-164-726-91 CERAMIC CHIP 9PF 0.50PF 50V (EA)
C10 1-162-934-11 CERAMIC CHIP 3PF 0.25PF 50V
(EXCEPT EA)
C11 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C12 1-162-916-11 CERAMIC CHIP 12PF 5% 50V (EA)
C12 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
(EXCEPT EA)
C13 1-162-942-11 CERAMIC CHIP 12PF 5% 50V (EA)
C13 1-162-939-11 CERAMIC CHIP 8PF 0.5PF 50V
(EXCEPT EA)
C14 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C17 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C18 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V (EA)
C18 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
(US, CND)
C18 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(EXCEPT US, CND, EA)
C21 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C22 1-115-156-11 CERAMIC CHIP 1uF 10V
C23 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C24 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, 5E)
C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT US, CND, 5E)
C25 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US, CND, 5E)
C25 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EXCEPT US, CND, 5E)
C26 1-137-934-91 TANTAL. CHIP 47uF 20% 10V
C27 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C28 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C29 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C30 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C31 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C32 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C101 1-115-156-11 CERAMIC CHIP 1uF 10V
C102 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(US, CND, EA, 5E)
C102 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(E, 9E, CH, TW)
C103 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C104 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C105 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C106 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C107 1-115-156-11 CERAMIC CHIP 1uF 10V
C108 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C109 1-115-156-11 CERAMIC CHIP 1uF 10V
C111 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C151 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C152 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C153 1-113-690-11 ELECT CHIP 220uF 20.00% 4V
C154 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C162 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C163 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C164 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C165 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C201 1-115-156-11 CERAMIC CHIP 1uF 10V
C202 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(US, CND, EA, 5E)
C202 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(E, 9E, CH, TW)
C203 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C204 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C205 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C206 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C209 1-115-156-11 CERAMIC CHIP 1uF 10V
C211 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C251 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C262 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
MAIN
Ver 1.2
