6
—
Note :
Follow the disassembly procedure in the numerical order given.
3-1.
BRACKET ASSEMBLY AND CASSETTE HOLDER ASSEMBLY
SECTION 3
DISASSEMBLY
4
Lock lever (B)
6
Cassette holder assembly
3-2.
TUNER BOARD
1
Three screws (1.7x2.5)
(tapping)
2
TU cover
Note for installation
3
Tuner board
3
Screw (M1.4x1.1)
2
Bracket assembly
5
Screw (M1.4x1.1)
1
Screw (M1.4x1.1)
5
7
Table of Contents
Default Chapter
2
Table of Contents
2
Section 1. General
3
Section 2. Service Note
4
Section 3. Disassembly
6
Tuner Board
6
Main Board
7
Section 4. Mechanical Adjustment
8
Section 5. Electrical Adjustment
8
IC Pin Functions
15
Ic501 Ba3641Fv Rec Amp
15
IC701 MSM63120B System Control
15
IC702 SMC62L3A LCD Drive
17
Section 7. Exploded Views
18
Case Section
18
Main Board Section
19
Mechanism Section (MF-WMGX614-112)
20
Section 8. Electrical Parts List
21
