SELF DIAGNOSTIC FUNCTION
The units in this manual contain a self-diagnostic function. If an error occurs, the Smart Core Red LED will automatically begin to flash. The number
of times the LED flashes translates to a probable source of the problem.
A definition of the Smart Core Red LED flash indicators is listed in the instruction manual for the user’s knowledge and reference.
If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past
problems and how often these problems occur.
DIAGNOSTIC TEST INDICATORS
When an error occurs, the Smart Core Red LED will flash a set number of times to indicate the possible cause of the problem. If there is
more than one error, the LED will identify the first of the problem areas.
Result for all of the following diagnostic items are displayed on screen. If the
screen displays a “0”, no error has occurred .
Self Diag. Quick Reference (LED blinking)
Notes :
Blue italic: detect at startup sequence only.
<G>: Power Supply board, <B>: Main board,
<T>: T-con board, <LD>: LD board,
<P>: Panel module,
<S>: Speaker,
Smart Core RED LED
blinking count
AS
2x <B/G> Main 12V over voltage [MAIN_POWER]
3x
<B/G> Main 5.0V failure [DC_ALERT]
<B/S/G> Audio amp. protection [AUD_ERR]
4x
<P/T/B/G>TCON internal error/TCON I2C communication failure [LD_ERR]
<P/T/G/B> EVDD failure [BCM_ERR]
5x
<P/T/G/B> Panel ID EEPROM I2C No ACK
(Also panel power failure is a suspect) [P_ID_ERR]
<T/B>Data corruption in EEPROM[P_ID_ERR]
6x <P/G/B> EVDD over voltage [BACKLIGHT_ERR]
7x <P/B> Over temperature protection [TEMP_ERR]
8x <B> 4KBE failure (4KBE WDT) [4KBE_ERR]
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSTMENT DIAGRAM HANDLING GUIDE
13
SYSSET
2021/02/0423:38:48(GMT+09:00)

Sony XR-65A90J Specifications

General

Screen Type	oled
Color	black
Wall Mount	300mm x 300mm
Features	explore the sony 65" options
Tuner	digital
Screen Size	64.5 inches, 65 inches
Resolution	4k (2160p)
Refresh Rate	120hz
Closed Captioning	yes
Motion Enhancement	xr motion clarity
HDR	yes
HDR Format	hdr 10, hybrid log-gamma (hlg), dolby vision
Built-In Speakers	true, front firing
Surround Sound	dts digital surround
HDMI Ports	4
HDMI 2.1 Ports	2
HDMI ARC Ports	yes
USB Ports	3
USB 2.0 Ports	2
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 4.2
Network	built-in wi-fi
Digital Optical Audio Outputs	1
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	google tv
Streaming Services	paramount+, disney+, hbo max, hulu, netflix, prime video, showtime, starz, sling tv, youtube, peacock
Smart Applications	amazon alexa, google assistant
Voice Assistant	amazon alexa, google assistant
Remote Control	voice control
3D	no
Power Consumption	228 kilowatt hours
Depth with Stand	12.5 inches
Height with Stand	32.87 inches
Width with Stand	59.25 inches
Net Weight with Stand	54.2 pounds
Depth without Stand	1.62 inches
Height without Stand	32.87 inches
Net Weight without Stand	49.6 pounds
