6. Front Cover
Lift up this cover to replace consumables or clear a paper jam.
7. Bypass Tray
This tray can hold one sheet of plain paper.
8. Tray 1
This tray can hold up to 150 sheets of plain paper.
9. Power Switch
Use this switch to turn the power on or off.
10. Power Connector
Connect the power cord to the machine here. Insert the other end of the cable into a nearby wall outlet.
11. Rear Cover
Open this cover to deliver sheets face up or remove jammed paper.
12. USB Port
Use this port to connect the machine to a computer using a USB cable.
13. Tray Cover
Attach this cover when you extend the tray.
Interior
1. Print Cartridge
A replacement consumable that is required to make prints on paper. It needs to be replaced after
approximately every 2600 pages printed. For details about replacing the cartridge, see p.27 "Replacing
the Print Cartridge".
Guide to Components
5
