POS DESCRIPTION NB
19 Holder 1
20 Knob Assembly 1
21 Gasket 1
22 Handle 1
23 Tube component 1
23.1 Tube 1
23.2 Screw 2
23.3 Connecting shelve 2
23.4 Tube 1
23.5 Tube 1
24 Spring connecting wire 1
25 Protective cover 1
26 Blade 1
27 Screw 1
28 Screw 1
29 Cabinet 1
30 Motor assembly 1
31 Cabinet 1
32 Gasket 1
33 Cutting grass head
Assembly
1
33.1 Cutting head base 1
33.2 Bolt 1
33.3 Gasket 2
33.4 Gasket 4
33.5 Sliding plate 1
33.6 Spring 1
33.7 Stopper 1
33.8 Glue 1
33.9 Wire seat 1
33.10 Nylon wire 4
33.11 Grass mowing head
cover
1
33.12 Nut 1
34 Tape
35 Flower guard 1
8.4 TROUBLESHOOTING
DANGER ! Risk of injury due to electric shock.
Warning ! Before any trouble shooting, switch off the product.
Problems Probable causes Solutions
Qualication
required
No engine stop
The OFF switch is defective
Test it and change it by a new
one
After sales
service
The trigger system is
defective
