7.2.1
When the cutting-means assembly is in the basic
setting, the best mulching eect and good disper-
sion of the cut grass are achieved.
The basic setting is recommended for grass of a
normal length. See 5.4.
7.2.2 Greater tilt
If the cutting-means assembly is tilted forward, the
mulching eect is reduced, improving the disper-
sion of cut grass.
It is advisable to tilt the cutting-means assembly
forward when tackling thick grass.
7.3 MOWING TIPS
To get the best mowing results, follow the tips
given below.
• Cut grass frequently.
• Run the machine at full revs.
• Grass should not be wet.
• Only use sharp cutting devices.
• Keep the bottom side of the cutting device
clean.
7.4 COMPOSTING / REAR DISCHARGE
Grass can be cut in two ways.
• Composting the grass on the lawn.
• Expulsion of grass from the back of the cutting
mean.
• text
When the machine is delivered the cutting-means
assembly is set for composting.
Expulsion of grass from the back of the cutting-
means assembly.
• Slacken and remove the screw (23:A) which
secures the deector in place (23:B).
• Remove the deector (23:B).
Keep the screw and the deector in a safe place
for future use.
8 MAINTENANCE
8.1 PREPARATION
All service and all maintenance checks
-
Always apply the parking brake to stop
the machine from moving. (please refer
-
gine.
-
-
nect the (negative) lead from the bat-
tery.
Remove the key from the ignition. (plea-
Wear protective gloves.
8.2 WASHING POSITION
1. Set the tool lift in the transport position.
2. Set the maximum cutting height.
Follow the indications provided in hea-
ding 3.7.
1. Remove the rear section of the cutting deck
assy as follows:
• Slightly lift the cutting-means assembly
to ease the load on the cotter pin or peg
(4:A).
• Remove the cotter pin or peg (4:A) and
the washer (4:C) on both cutting-means
assembly arms.
It is strictly forbidden to start the engi-
ne when the deck is in the washing po-
sition.
2. Take hold of the front cutting-means assem-
bly edge (24:A) and lift. Hook-up the chain
(24:B) so that the cutting-means assembly is
pointing upwards diagonally.
3. Clean the cutting-means assembly.
4. Once the washing operation has been
completed, reposition the cutting-means
assembly in its initial position and replace the
washer and cotter pin or peg on both sides.
8.3 MAINTENANCE POSITION
8.3.1
Example of xed mounts, see (5:C and 6:A).
1. Remove the belt guard as follows:
Park 2WD, 4WD / Castelgarden:
• Slacken and remove the screw (15:A).
