1. GENERAL
1.1 HOW TO READ THIS MANUAL
In this manual, certain paragraphs containing
particularly important information for operator
safety and machine operation are highlighted in
dierent ways according to the following criteria.
NOTE or IMPORTANT indicates
clarications or other elements concerning the
information provided for the purpose of avoiding
damage to the machine or causing any harm.
The symbol highlights a hazard.. Failure to
observe the warning may lead to personal injury
or injury to others and/or material damage.
The paragraphs highlighted in a box
with a dotted grey edge indicate optional
features which may not be present on all
the models covered by this manual. Check
if your model as the feature in question.
All the indications "front", "back", "left"
and "right" refer to the position of the
operator when driving the machine.
1.2 REFERENCES
1.2.1 Figures
The gures in this User Manual are
numbered 1, 2, 3 and so on.
Components shown in the gures
are marked A, B, C, etc.
A reference to component C in gure 2 is
written as: “See g. 2.C” or simply “(Fig. 2.C)”.
All gures are indicative. Parts on your
machine may vary from those shown.
1.2.2 Titles
This manual is divided into chapters and
paragraphs. The title of the paragraph
“2.1 Training” is a subheading in chapter 2
"Safety regulations". References to titles or
paragraphs are indicated with the abbreviation
"chap." or "par." accompanied by the relative
number. Example: “chap. 2” or “par. 2.1”.
EN
INDEX
1. GENERAL .................................................... 1
2. SAFETY REGULATIONS .............................. 2
2.4 Maintenance, storage and transport...... 3
3. MACHINE INFORMATION ........................... 3
3.1 Description of the machine and its
intended use ......................................... 3
3.2 Warning signs ....................................... 4
3.3 Identication label ................................ 4
3.4 Main components ................................. 4
4. INSTALLATION ............................................. 5
4.1 Assembly components .......................... 5
4.2 Assembly of the cutting means device .. 5
4.3 Hooking up the cutting means assembly
to the ride-on lawnmower. ..................... 5
4.4 Unooking the cutting means assembly
from the ride-on lawnmower. ................. 6
5. CONTROL COMMANDS ............................. 6
5.1 Cutting height adjustment ..................... 6
5.2 “Quick Flip” knob ................................... 6
6. USING THE MACHINE ................................. 7
6.1 Preliminary operations .......................... 7
6.2 Safety checks ........................................ 7
6.3 Start-up / operation ............................... 7
6.4 After use ................................................ 7
7. ROUTINE MAINTENANCE .......................... 7
7.1 General Information .............................. 7
7.2 Washing and maintenance position ...... 8
7.3 Fasteners .............................................. 8
7.4 Cleaning ................................................ 8
8. UNSCHEDULED MAINTENANCE ............... 8
8.1 Checking and replacing the cutting
device ................................................... 8
8.2 Checking and replacing the cutting
means drive belt .................................... 8
9. STORAGE .................................................... 9
10. ASSISTANCE AND REPAIRS ....................... 9
11. HANDLING AND TRANSPORT .................... 9
12. WARRANTY COVERAGE ............................ 9
13. MAINTENANCE TABLE .............................. 10
14. TROUBLESHOOTING ............................... 10
