16
ENGLISH
EN
1 GENERAL
This symbol indicates WARNING.
Personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions and
the accompanying pamphlet “SAFETY
INSTRUCTIONS” carefully, before the
assembly begin.
2 ASSEMBLY
To avoid injury and damage to people
and property, do not use the machine
until all the measures in this instruction
have been carried out..
2.1 Assembly components
Components that are to be used at assembly are in-
cluded in the delivery. See fig. 1.
Supplied in bag:
Pos No. Designation Dimension
A 1 Towing plate
B 2 Screw with flange 8 x 20
C 2 Screw for battery
D 2 Nut for battery
E 4 Washer 8.4 x 24 x 2.0
F 2 Shoulder washer
G 4 Screw 8 x 20
H 2 Screw knob
I 2 Ignition key
J 1 Tension pin 6 x 36
K 1 Shim washer 16 x 38 x 0.5
L 1 Shim washer 16 x 38 x 1.0
P 2 Screw M10 x 35
Q2 Nut M10
Supplied installed on the front axles:
Pos No. Designation
M2 Circlip
N 2 Washer with internal lug
Secured to the implement lifter:
Pos No. Designation
O 2 Deck mount
2.2 References
The figures in these instructions for use are
numbered 1, 2, 3, etc.
Components shown in the figures are marked A, B,
C, etc.
A reference to component C in figure 2 is written
“2:C”.
2.3 Engine casing
To fill with fuel and to inspect and maintain the en-
gine and battery, open the engine casing.
The engine must not be running when
the casing is opened.
2.3.1 Opening
1. Ensure that the control arms are in their forward
positions.
2. Raise the seat lock (2:S) and fold the seat for-
wards.
3. Grasp the front edge of the engine casing and
fold up the casing (fig. 3).
2.3.2 Closing
Grasp the front edge of the engine casing and fold
down the casing (fig. 3).
The machine may not be operated un-
less the engine casing is folded down.
Risk of burns and crushing injuries.
2.4 Battery
Never overcharge the battery. Over-
charging can damage the battery.
Do not short-circuit the battery’s termi-
nals. Sparks occur which can result in
fire. Do not wear metal jewellery which
can come into contact with the battery
terminals.
In the event of damage to the battery casing,
cover, terminals or interference to the strip cov-
ering the valves, the battery should be replaced.
The battery is a valve-regulated battery with 12 V
nominal voltage. The battery fluid does not need to
and cannot be checked or topped up. The only
maintenance that is required is charging, for exam-
ple after extended storage.
The battery must be fully charged be-
fore being used for the first time. The
battery must always be stored fully
charged. If the battery is stored while
discharged, serious damage will occur.
2.4.1 Charging with the engine
The battery can be charged using the engine’s gen-
erator as follows:
1. Install the battery in the machine as shown be-
low.
2. Place the machine outdoors or install an extrac-
tion device for the exhaust fumes.
3. Start the engine according to the instructions in
the user guide.
4. Allow the engine to run continuously for 45
minutes.
5. Stop the engine. The battery will now be fully
charged.
