18
ENGLISH
EN
2.8 Deck mount
This only describes installation on the right-hand
axle. The same procedure must be carried out on
the left-hand axle.
1. Remove the circlip (7:M) and the outer washer
(7:N).
2. Install the deck mount (7:O).
The washer (7:N) with an inner lug
must always be placed against the cir-
clip. Otherwise there is a risk of the cir-
clip coming loose.
3. Install the outer washer (7:N) and the circlip
(7:M).
4. Lubricate the deck mount’s lubricating cup us-
ing a grease gun until grease penetrates along
side the axle.
The screws (1:P) and the nuts (1:Q) must be used
to install the work tool in the deck arms (5:O).
2.9 Tyre pressure
Check the air pressure in the tyres. Correct air
pressure:
Front: 0.4 bar (6 psi)
Rear: 1.2 bar (17 psi)
2.10Accessories
For the installation of accessories, see separate
installation guide supplied with each accessory.
Note: The cutting deck is regarded as an accessory
here.
