Stihl BG 86 User Manual

BG 56, BG 56 C, BG 66, BG 86, BG 86 C, SH 56, SH 56 C, SH 86, SH 86 C
English
25
1 Setting Lever (BG 86, SH 86)
2 Spark Plug Boot
3 Muffler
4 Starter Grip
5 Carburetor Adjusting Screws
6 Manual Fuel Pump
7 Choke Lever
8 Filter Housing
9 Filter Cover Lock
10 Fuel Filler Cap
11 Fuel Tank
12 Assist Handle
13 Control Handle
14 Stop Switch (BG 56, BG 66, SH 56)
15 Throttle Trigger
16 Intake Screen
17 Union Nut
18 Blower Tube (BG 56, BG 86,
SH 56, SH 86)
19 Round Nozzle
20 Fan Nozzle
*
21 Suction Tube
*
22 Elbow
*
23 Catcher Bag
*
24 Blower Tube Silencer (BG 66)
# Serial number
* Depending on version – special
accessory
Main Parts
7
8
2
3
17
13
14
15
296BA003 KN
4
1
9
5
6
20
19
18
16
12
10
11
#
21
22
23
24

Stihl BG 86 Specifications

General

Type	Handheld blower
Airflow	810 m³/h
Suction mode	-
Product color	Black, Orange, White
Airspeed (max)	306 km/h
Airspeed (min)	248.4 km/h
Power source	Gasoline
Vibration emission	2.5 m/s²
Sound pressure level	90 dB

Weight and Dimensions

Weight	4400 g
