Stihl FC 91 User Manual

FC 91
English
14
The loop handle can be adjusted to suit
the height and reach of the operator and
the application by changing
distance (A).
Recommendation: distance (A):
about 6 in (15 cm)
N Slide the handle to the required
position.
N Tighten down the screw with the
combination wrench so that the
handle cannot be rotated on the
drive tube.
It may be necessary to correct the
adjustment of the throttle cable after
assembling the machine or after a
prolonged period of operation.
Adjust the throttle cable only when the
unit is completely and properly
assembled.
N Set the throttle trigger to the full
throttle position.
N Carefully rotate the screw in the
throttle trigger in the direction of the
arrow until you feel initial resistance.
Then rotate it another half turn in the
same direction.
N Place the edger so that the blade
mounting (1) faces upwards
N Insert the locking pin (2) as far as
possible into the bore (3), push
lightly and rotate back and forth a
little together with the thrust washer
(4) until the shaft is blocked.
N Fit Allen wrench (5) onto nut (6).
A
0000-GXX-1562-A0
Adjusting the Throttle Cable
002BA655 KN
Mounting the Cutting Blade
239BA020 KN
6
239BA021 KN
3
2
4
5
