Stihl FC 95 User Manual

FC 95, FC 110
English
33
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
CARB
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Engine
STIHL single cylinder four-stroke engine
with mixture lubrication
FC 95
FC 110
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Weight
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Displacement: 1.73 cu.in 28.4 cc
Bore: 1.5 in (38 mm)
Stroke: 0.98 in (25 mm)
Engine power to
ISO 8893:
1.3 bhp (0.95 kW)
at 7,000 rpm
Idle speed: 2,800 rpm
Cut-off speed
(rated): 10,500 rpm
Valve clearance:
Inlet valve: 0.004 in (0.10 mm)
Exhaust valve: 0.004 in (0.10 mm)
Displacement: 1.92 cu.in 31.4 cc
Bore: 1.57 in (40 mm)
Stroke: 0.98 in (25 mm)
Engine power to
ISO 8893:
1.34 bhp (1.05 kW)
at 7,000 rpm
Idle speed: 2,800 rpm
Cut-off speed
(rated): 10,500 rpm
Valve clearance:
Inlet valve: 0.004 in (0.10 mm)
Exhaust valve: 0.004 in (0.10 mm)
Spark plug (resistor
type): Bosch USR 7 AC
Electrode gap: 0.02 in (0.5 mm)
Fuel tank capacity: 17.9 fl.oz (0.53 L
dry, with deflector
and blade 15.0 lbs (6.8 kg)

Stihl FC 95 Specifications

General

Brand	Stihl
Model	FC 95
Category	Trimmer
Language	English
