Stihl FS 360 User Manual

FS 260 C, FS 360 C
English
17
Adjusting the Handlebar
Opening the wing screw
N Raise the grip of the wing screw to
the upright position.
N Turn the wing screw
counterclockwise until the handle
support can be moved.
N Move the handlebar to the required
position.
Closing the wing screw
N Turn the wing screw clockwise as
far as stop.
N Fold the grip of the wing screw down
so that it is flush.
Swiveling the Handlebar
Transport position
N Loosen the wing screw (7) and
unscrew it until the handlebar (2)
can be turned clockwise.
N Turn the handlebar 90° and then
swing the handles down.
N Tighten down the wing screw (7)
firmly.
Working position
N Reverse the sequence described
above to swing the handles up and
turn the handlebar
counterclockwise.
6BA023 KN
6BA004 KN
6BA007 KN
6BA005 KN
6BA006 KN
7
6BA008 KN
2
