Contents
1 Guide to Using this Manual.........................2
2 Safety Precautions and Working Techni‐
ques............................................................ 2
3 Using the Unit............................................. 7
4 Mounting the Drive Tube.............................8
5 Mounting the Loop Handle..........................9
6 Mounting the Gearbox................................ 9
7 Adjusting the Cutter Bar............................10
8 Fitting the Harness....................................11
9 Connecting to Power Supply.....................11
10 Switching On.............................................12
11 Switching Off.............................................12
12 Overload Cutout........................................12
13 Lubricating the Gearbox............................13
14 Storing the Machine.................................. 13
15 Sharpening Instructions............................ 13
16 Maintenance and Care..............................14
17 Minimize Wear and Avoid Damage...........14
18 Main Parts.................................................15
19 Specifications............................................15
20 Maintenance and Repairs......................... 16
21 Disposal.................................................... 16
22 EC Declaration of Conformity................... 17
23 UKCA Declaration of Conformity.............. 17
24 General Power Tool Safety Warnings.......18
Dear Customer,
Thank you for choosing a quality engineered
STIHL product.
It has been built using modern production techni‐
ques and comprehensive quality assurance.
Every effort has been made to ensure your satis‐
faction and trouble-free use of the product.
Please contact your dealer or our sales company
if you have any queries concerning this product.
Your
Dr. Nikolas Stihl
1 Guide to Using this Manual
1.1 Pictograms
All the pictograms attached to the machine are
shown and explained in this manual.
1.2 Symbols in text
WARNING
Warning where there is a risk of an accident or
personal injury or serious damage to property.
NOTICE
Caution where there is a risk of damaging the
machine or its individual components.
1.3 Engineering improvements
STIHL's philosophy is to continually improve all
of its products. For this reason we may modify
the design, engineering and appearance of our
products periodically.
Therefore, some changes, modifications and
improvements may not be covered in this man‐
ual.
2 Safety Precautions and
Working Techniques
Because this unit is a high-speed,
fast-cutting tool powered by electricity
and has very sharp cutting blades
and a long reach, special safety pre‐
cautions must be observed during
operation.
It is important you read and under‐
stand the User Manual before com‐
missioning and keep it in a safe place
for future reference. Non-compliance
with the User Manual may cause seri‐
ous or even fatal injury.
Observe all applicable local safety regulations,
e.g. by trade organizations, social insurance
institutions, labor safety authorities etc.
If you have never used a power tool before:
Have your dealer or other experienced user
show you how to operate your machine – or
attend a special course to learn how to operate
it.
Minors are not allowed to work with the power
tool – except adolescents above 16 years of age
who are instructed under supervision.
Children, animals and bystanders must remain at
a distance.
When not using the machine, it must be laid
down in such a way that it does not endanger
anyone. Ensure that the machine cannot be
used without authorization.
English
2 0458-277-0121-B
© ANDREAS STIHL AG & Co. KG 2021
0458-277-0121-B. VA0.G21.
Printed on chlorine-free paper
Printing inks contain vegetable oils, paper can be recycled.
Original Instruction Manual
0000000888_020_GB
