HT 102, HT 103, HT 132, HT 133
English
34
The drive link tangs will otherwise
scrape along the bottom of the groove –
the cutters and tie straps will not ride on
the bar rails.
Filters have an average life of more than
a year. Do not remove the filter cover or
replace the air filter as long as there is no
noticeable loss of power.
If there is a noticeable loss of engine
power
N Turn the choke knob to g.
N Loosen the screws (1).
N Remove the filter cover (2).
N Clean away loose dirt from around
the filter.
N Remove the filter element (3).
N Replace dirty or damaged filter
element (3).
N Replace any damaged parts.
Installing the Filter Element
N Install the filter element (3) in the
filter housing and fit the cover.
N Insert the screws (1) and tighten
them down firmly.
Exhaust emissions are controlled by the
design of the engine and components
(e.g. carburation, ignition, timing and
valve or port timing).
Replacing the Air Filter
Engine Management
