Stihl HT 132 User Manual

HT 102, HT 103, HT 132, HT 133
English
35
The carburetor has been set at the
factory to provide an optimum fuel-air
mixture under most operating
conditions.
Adjusting Idle Speed
Engine stops while idling
N Warm up the engine for about
3 minutes.
N Turn the idle speed screw (LA)
slowly clockwise until the engine
runs smoothly – the saw chain must
not rotate.
Chain rotates when engine is idling
N Turn the idle speed screw (LA)
counterclockwise until the chain
stops running and then turn the
screw another 1/2 to 3/4 turn in the
same direction.
WARNING
If the chain continues moving when the
engine is idling, have your power tool
checked and repaired by your servicing
dealer.
N If the engine is down on power,
check the spark arresting screen in
the muffler.
N Wait for the muffler to cool down.
N Take out the screw (4).
N Lift the spark arresting screen (5)
and pull it out.
N Clean the spark arresting
screen (5). If the screen is damaged
or heavily carbonized, install a new
one.
N Refit the spark arresting screen (5).
N Insert the screw (4) and tighten it
down firmly.
If there is a loss of engine power, the
machine is difficult to start or runs poorly
at idle, first check the spark plug.
Install a new spark plug after
approximately 100 operating hours or
earlier if the electrodes are
eroded/corroded.
The wrong fuel mix (too much engine oil
in the gasoline), a dirty air filter and
unfavorable running conditions (mostly
at part throttle etc.) affect the condition
of the spark plug. These factors cause
deposits to form on the insulator nose,
which may degrade performance.
Removing the Spark Plug
N Remove the cover (1).
N Pull off the spark plug boot (2).
N Unscrew the spark plug (3).
Adjusting the Carburetor
0000-GXX-0495-A0
Spark Arresting Screen in
Muffler
0000-GXX-0486-A0
4
5
Spark Plug
3
2
1
0000-GXX 0537-A0
