2.1 General
This instruction manual constitutes
original manufacturer’s instructions in
the sense of EC Directive 2006/42/EC.
STIHL is continually striving to further
develop its range of products; we therefore
reserve the right to make alterations to the
form, technical specifications and
equipment level of our standard
equipment.
For this reason, the information and
illustrations in this manual are subject to
alterations.
This instruction manual may describe
models that are not available in all
countries.
This instruction manual is protected by
copyright. All rights reserved, especially
the right of reproduction, translation and
processing using electronic systems.
2.2 Instructions for reading the
instruction manual
Illustrations and texts describe specific
operating steps.
All symbols which are affixed to the
machine are explained in this instruction
manual.
Viewing direction:
Viewing direction when "left" and "right"
are used in the instruction manual:
the user is standing behind the machine
and is looking forwards in the direction of
travel.
Section reference:
References to relevant sections and
subsections for further descriptions are
made using arrows. The following example
shows a reference to a section: (Ö 4.)
Designation of text passages:
The instructions described can be
identified as in the following examples.
Operating steps which require intervention
on the part of the user:
● Release bolt (1) using a screwdriver,
operate lever (2)...
General lists:
– Use of the product for sporting or
competitive events
Texts with added significance:
Text passages with added significance are
identified using the symbols described
below in order to especially emphasise
them in the instruction manual:
Texts relating to illustrations:
Some Illustrations which are necessary for
use of the machine can be found at the
front of this instruction manual.
The camera symbol serves to link
the figures on the illustration pages
with the corresponding text
passages in the instruction manual.
Illustrations with text passages:
Operating steps relating directly to the
illustration can be found immediately after
the illustration, with a corresponding
reference to the item numbers.
Example:
Transport 32
Transporting the tiller 32
Environmental protection 33
Disposal 33
Minimising wear and preventing
damage 33
Standard spare parts 34
EU - Declaration of conformity 34
Petrol tiller (STIHL MH) 34
Technical specifications 35
REACH 35
Troubleshooting 35
Service schedule 37
Handover confirmation 37
Service confirmation 37
2. Notes on the instruction
manual
Danger
Risk of accident and severe injury
to persons. A certain type of
behaviour is necessary or must be
avoided.
Warning
Risk of injury to persons. A certain
type of behaviour prevents possible
or probable injuries.
Caution
Minor injuries or material damage
can be prevented by a certain type
of behaviour.
Note
Information for better use of the
machine and in order to avoid
possible operating errors.
