32 MS 192 T
: Pull out the insulating plate (1),
pressing the locking lug together
at the bottom guide (arrow).
217RA072 TG
1
: Disconnect the impulse hose (1)
from the stub (arrow).
217RA104 TG
1
: Remove the screws (arrows) on
the carburetor side.
217RA105 TG
: Remove the screws (arrows)
from underneath the engine
housing.
217RA106 TG
: Lift the handle housing slightly
until the manifold flange lifts off
the intake stub.
217RA153 TG
: Pull the engine out of the engine
housing.
217RA110 TG
: Push engine into engine housing.
217RA152 TG
: Lift the handle housing slightly so
that the intake stub can be
positioned in relation to the
manifold when fitting the engine.
217RA153 TG
: Fit the screws (arrows) and
tighten them down only
moderately.
217RA105 TG
8.4.2 Installation
