Stihl MS 201 TC-M User Manual

MS 241 C-M
English
41
Exhaust emissions are controlled by the
design of the fundamental engine
parameters and components (e.g.
carburation, ignition, timing and valve or
port timing) without the addition of any
major hardware.
Basic information
M-Tronic regulates the fuel quantity and
ignition timing for all operating states
electronically.
M-Tronic stands for easy, fast starting,
constant optimum engine performance,
outstanding acceleration and automatic
adaptation to changes in operating
conditions.
Manual carburetor adjustments are no
longer required – the carburetor does
not have any adjusting screws.
Automatic adjustment
Under extremely changed operating
conditions, attainment of the optimal
setting can be accelerated as follows:
N Carry out five uniform cuts to length
under full load
N If engine performance deteriorates,
check the spark arresting screen in
the muffler
N Let the muffler cool down
N Unscrew the screw (1)
N Pull out spark arresting screen (2)
N Clean the dirty spark arresting
screen, replace if damaged or
heavily carbonized
N Refit the spark arresting screen
N Fit screw
Engine Management M-Tronic Spark Arresting Screen in
Muffler
2310BA023 KN
2
1

Stihl MS 201 TC-M Specifications

General

Idle speed	3000 RPM
Motor type	2-stroke motor
Chain pitch	3/8 \
Blade length	350 mm
Product color	Black, Grey, Orange
Motor speed (max)	10500 RPM
Oil tank capacity	0.22 L
Fuel tank capacity	0.31 L
Engine displacement	35.2 cm³
Kickback protection	Yes
Engine power	2.4 hp
Power source	Gasoline
Sound power level	113 dB
Vibration emission	3.5 m/s²
Sound pressure level	100 dB

Weight and Dimensions

Weight	3700 g
