Stihl MSA 161 T User Manual

0458-791-8221-C
48
English 24 Inspection and Maintenance
23.2 Cleaning the Guide Bar and Saw Chain
WARNING
To reduce the risk of personal injury from unintended
activation, remove the battery and engage the chain brake
before carrying out any cleaning work, @ 8. Users of this
chain saw should carry out only the cleaning described in
this manual.To help prevent injuries, always wear heavy-
duty work gloves when handling the chain.
To properly clean the guide bar and chain:
► Remove the guide bar and the chain, @ 15.2.2.
► Clean the oil outlet duct (1), oil inlet bore (2) and groove
(3) with a brush, a slightly dampened cloth or resin
solvent, such as STIHL Resin Remover & Lubricant. Do
not use detergents.
► Clean the chain with a brush, a slightly dampened cloth or
resin solvent. Do not use detergents.
► Do not use a pressure washer to clean the guide bar or
chain or otherwise spray them with water or other liquids.
24.1 Inspecting and Maintaining the Chain Saw
WARNING
To reduce the risk of personal injury from unintended
activation, remove the battery before inspecting the chain
saw or carrying out any maintenance, @ 9. Carry out only
the maintenance operations described in this manual. There
are no user-authorized repairs. STIHL recommends that
repair work be performed by authorized STIHL servicing
dealers.
Proper maintenance of the chain saw includes the following
activities:
► Inspecting the chain sprocket periodically and having a
worn chain sprocket replaced by an authorized STIHL
servicing dealer.
► Inspecting the guide bar for proper groove depth and
spread and replacing the guide bar it if it shows signs of
excessive wear or damage.
► Periodically sharpening the chain, maintaining the depth
limiting guides at the appropriate height and replacing the
saw chain when indicated by the relevant wear marks or
when the chain is damaged or shows signs of excessive
wear.
► Having worn, missing or damaged safety labels replaced
by an authorized STIHL servicing dealer.
If you make a warranty claim for a component which has not
been serviced or maintained properly, coverage may be
denied.
24.2 Inspecting and Maintaining the Chain Sprocket
► Switch off the chain saw, engage the chain brake and
remove the battery.
► Disengage the chain brake, @ 16.2.
► Remove the chain sprocket cover, saw chain and guide
bar.
1
2
3
3
0000-GXX-3212-A1
24 Inspection and Maintenance

Stihl MSA 161 T Specifications

General

Idle speed	- RPM
Chain pitch	1/4 \
Blade length	250 mm
Product color	Black, Grey, Orange
Quick stop function	Yes
Power source	Battery
Battery voltage	36 V
Sound power level	94 dB
Vibration emission	2.2 m/s²
Sound pressure level	83 dB

Weight and Dimensions

Weight	2500 g
