Stihl RE 471 User Manual

RE 361, RE 361 PLUS, RE 461, RE 461 PLUS, RE 471 PLUS
English
49
1 Spray gun
2 Coupling for spray lance
3 Pressure and flow control setting
lever
4 Safety catch
5 Lever
6 Safety latch for high-pressure hose
7 Union nut for high-pressure hose
8 Nozzle
9 Selector sleeve for the working
pressure
10 Rotary nozzle
1)
11 High-pressure hose
12 Connector water intake
13 Connector high-pressure hose
14 Oil level check
15 Pressure/quantity control knob
16 Pressure gauge
17 Detergent metering knob
18 Machine switch
19 Detergent tank
20 Holder for spray attachment
21 Bracket for the power cable and
high-pressure hose
22 Hose reel
1)
23 Hose reel brake
1)
24 Hose reel crank handle
1)
# Model plate
Main Parts
23
22
12
12
19
13
16
17
16
19
17
14
15
24
18
20
21
21
20
14
15
18
21
#
#
671BA028 KN
2
9
3
6
7
1
4
8
11
10
1)
PLUS models only

Stihl RE 471 Specifications

General

Brand	Stihl
Model	RE 471
Category	Pressure Washer
Language	English
