RE 88
English
10
Connector on water inlet
N Attach the connector (6) to the water
inlet by hand and tighten it
Spray lance
N Press the spray lance (1) into the
mount on the spray gun (2), turn it
by 90° so that it engages
Remove
N Press the spray lance (1) into the
mount on the spray gun (2), turn it
by 90° and pull it out of the mount
Nozzle
N Insert nozzle (3) in spray lance until
the safety latch (4) engages – at
which point the safety latch button
will spring out again – the adjustable
high-pressure nozzle has an anti-
twist device; orient this according to
the groove on the spray lance
Remove
N Press the safety latch button (4) and
pull out the nozzle (3)
